import numpy as np, pandas as pd
from matplotlib.pyplot import subplots
from sklearn.linear_model import \
(LinearRegression,
LogisticRegression,
Lasso)
from sklearn.preprocessing import StandardScaler
from sklearn.model_selection import KFold
from sklearn.pipeline import Pipeline
from ISLP import load_data
from ISLP.models import ModelSpec as MS
from sklearn.model_selection import \
(train_test_split,
GridSearchCV)
In this section we demonstrate how to fit the examples discussed in the text. We use the Python torch package, along with the pytorch_lightning package which provides utilities to simplify fitting and evaluating models. This code can be impressively fast with certain special processors, such as Apple’s new M1 chip. The package is well-structured, flexible, and will feel comfortable to Python users. A good companion is the site pytorch.org/tutorials. Much of our code is adapted from there, as well as the pytorch_lightning documentation. {The precise URLs at the time of writing are https://pytorch.org/tutorials/beginner/basics/intro.html and https://pytorch-lightning.readthedocs.io/en/latest/.}
We start with several standard imports that we have seen before.
Torch-Specific Imports
There are a number of imports for torch. (These are not included with ISLP, so must be installed separately.) First we import the main library and essential tools used to specify sequentially-structured networks.
import torch
from torch import nn
from torch.optim import RMSprop
from torch.utils.data import TensorDatasetThere are several other helper packages for torch. For instance, the torchmetrics package has utilities to compute various metrics to evaluate performance when fitting a model. The torchinfo package provides a useful summary of the layers of a model. We use the read_image() function when loading test images in Section~.
If you have not already installed the packages torchvision and torchinfo you can install them by running pip install torchinfo torchvision. We can now import from torchinfo.
from torchmetrics import (MeanAbsoluteError,
R2Score)
from torchinfo import summaryThe package pytorch_lightning is a somewhat higher-level interface to torch that simplifies the specification and fitting of models by reducing the amount of boilerplate code needed (compared to using torch alone).
from pytorch_lightning import Trainer
from pytorch_lightning.loggers import CSVLoggerIn order to reproduce results we use seed_everything(). We will also instruct torch to use deterministic algorithms where possible.
from pytorch_lightning import seed_everything
seed_everything(0, workers=True)
torch.use_deterministic_algorithms(True, warn_only=True)Seed set to 0We will use several datasets shipped with torchvision for our examples: a pretrained network for image classification, as well as some transforms used for preprocessing.
from torchvision.io import read_image
from torchvision.datasets import MNIST, CIFAR100
from torchvision.models import (resnet50,
ResNet50_Weights)
from torchvision.transforms import (Resize,
Normalize,
CenterCrop,
ToTensor)We have provided a few utilities in ISLP specifically for this lab. The SimpleDataModule and SimpleModule are simple versions of objects used in pytorch_lightning, the high-level module for fitting torch models. Although more advanced uses such as computing on graphical processing units (GPUs) and parallel data processing are possible in this module, we will not be focusing much on these in this lab. The ErrorTracker handles collections of targets and predictions over each mini-batch in the validation or test stage, allowing computation of the metric over the entire validation or test data set.
from ISLP.torch import (SimpleDataModule,
SimpleModule,
ErrorTracker,
rec_num_workers)In addition we have included some helper functions to load the IMDb database, as well as a lookup that maps integers to particular keys in the database. We’ve included a slightly modified copy of the preprocessed IMDb data from keras, a separate package for fitting deep learning models. This saves us significant preprocessing and allows us to focus on specifying and fitting the models themselves.
from ISLP.torch.imdb import (load_lookup,
load_tensor,
load_sparse,
load_sequential)Finally, we introduce some utility imports not directly related to torch. The glob() function from the glob module is used to find all files matching wildcard characters, which we will use in our example applying the ResNet50 model to some of our own images. The json module will be used to load a JSON file for looking up classes to identify the labels of the pictures in the ResNet50 example.
from glob import glob
import jsonSingle Layer Network on Hitters Data
We start by fitting the models in Section~ on the Hitters data.
Hitters = load_data('Hitters').dropna()
n = Hitters.shape[0]We will fit two linear models (least squares and lasso) and compare their performance to that of a neural network. For this comparison we will use mean absolute error on a validation dataset. \begin{equation*} \begin{split} \mbox{MAE}(y,\hat{y}) = \frac{1}{n} \sum_{i=1}^n |y_i-\hat{y}_i|. \end{split} \end{equation*} We set up the model matrix and the response.
model = MS(Hitters.columns.drop('Salary'), intercept=False)
X = model.fit_transform(Hitters).to_numpy()
Y = Hitters['Salary'].to_numpy()The to_numpy() method above converts pandas data frames or series to numpy arrays. We do this because we will need to use sklearn to fit the lasso model, and it requires this conversion. We also use a linear regression method from sklearn, rather than the method in Chapter~3 from statsmodels, to facilitate the comparisons.
We now split the data into test and training, fixing the random state used by sklearn to do the split.
(X_train,
X_test,
Y_train,
Y_test) = train_test_split(X,
Y,
test_size=1/3,
random_state=1)Linear Models
We fit the linear model and evaluate the test error directly.
hit_lm = LinearRegression().fit(X_train, Y_train)
Yhat_test = hit_lm.predict(X_test)
np.abs(Yhat_test - Y_test).mean()259.7152883314627Next we fit the lasso using sklearn. We are using mean absolute error to select and evaluate a model, rather than mean squared error. The specialized solver we used in Section~ uses only mean squared error. So here, with a bit more work, we create a cross-validation grid and perform the cross-validation directly.
We encode a pipeline with two steps: we first normalize the features using a StandardScaler() transform, and then fit the lasso without further normalization.
scaler = StandardScaler(with_mean=True, with_std=True)
lasso = Lasso(warm_start=True, max_iter=30000)
standard_lasso = Pipeline(steps=[('scaler', scaler),
('lasso', lasso)])We need to create a grid of values for \lambda. As is common practice, we choose a grid of 100 values of \lambda, uniform on the log scale from lam_max down to 0.01*lam_max. Here lam_max is the smallest value of \lambda with an all-zero solution. This value equals the largest absolute inner-product between any predictor and the (centered) response. {The derivation of this result is beyond the scope of this book.}
X_s = scaler.fit_transform(X_train)
n = X_s.shape[0]
lam_max = np.fabs(X_s.T.dot(Y_train - Y_train.mean())).max() / n
param_grid = {'lasso__alpha': np.exp(np.linspace(0, np.log(0.01), 100))
* lam_max}Note that we had to transform the data first, since the scale of the variables impacts the choice of \lambda. We now perform cross-validation using this sequence of \lambda values.
cv = KFold(10,
shuffle=True,
random_state=1)
grid = GridSearchCV(standard_lasso,
param_grid,
cv=cv,
scoring='neg_mean_absolute_error')
grid.fit(X_train, Y_train);We extract the lasso model with best cross-validated mean absolute error, and evaluate its performance on X_test and Y_test, which were not used in cross-validation.
trained_lasso = grid.best_estimator_
Yhat_test = trained_lasso.predict(X_test)
np.fabs(Yhat_test - Y_test).mean()235.6754837478029This is similar to the results we got for the linear model fit by least squares. However, these results can vary a lot for different train/test splits; we encourage the reader to try a different seed in code block 12 and rerun the subsequent code up to this point.
Specifying a Network: Classes and Inheritance
To fit the neural network, we first set up a model structure that describes the network. Doing so requires us to define new classes specific to the model we wish to fit. Typically this is done in pytorch by sub-classing a generic representation of a network, which is the approach we take here. Although this example is simple, we will go through the steps in some detail, since it will serve us well for the more complex examples to follow.
class HittersModel(nn.Module):
def __init__(self, input_size):
super(HittersModel, self).__init__()
self.flatten = nn.Flatten()
self.sequential = nn.Sequential(
nn.Linear(input_size, 50),
nn.ReLU(),
nn.Dropout(0.4),
nn.Linear(50, 1))
def forward(self, x):
x = self.flatten(x)
return torch.flatten(self.sequential(x))The class statement identifies the code chunk as a declaration for a class HittersModel that inherits from the base class nn.Module. This base class is ubiquitous in torch and represents the mappings in the neural networks.
Indented beneath the class statement are the methods of this class: in this case __init__ and forward. The __init__ method is called when an instance of the class is created as in the cell below. In the methods, self always refers to an instance of the class. In the __init__ method, we have attached two objects to self as attributes: flatten and sequential. These are used in the forward method to describe the map that this module implements.
There is one additional line in the __init__ method, which is a call to super(). This function allows subclasses (i.e. HittersModel) to access methods of the class they inherit from. For example, the class nn.Module has its own __init__ method, which is different from the HittersModel.__init__() method we’ve written above. Using super() allows us to call the method of the base class. For torch models, we will always be making this super() call as it is necessary for the model to be properly interpreted by torch.
The object nn.Module has more methods than simply __init__ and forward. These methods are directly accessible to HittersModel instances because of this inheritance. One such method we will see shortly is the eval() method, used to disable dropout for when we want to evaluate the model on test data.
hit_model = HittersModel(X.shape[1])The object self.sequential is a composition of four maps. The first maps the 19 features of Hitters to 50 dimensions, introducing 50\times 19+50 parameters for the weights and intercept of the map (often called the bias). This layer is then mapped to a ReLU layer followed by a 40% dropout layer, and finally a linear map down to 1 dimension, again with a bias. The total number of trainable parameters is therefore 50\times 19+50+50+1=1051.
The package torchinfo provides a summary() function that neatly summarizes this information. We specify the size of the input and see the size of each tensor as it passes through layers of the network.
summary(hit_model,
input_size=X_train.shape,
col_names=['input_size',
'output_size',
'num_params'])/home/oren/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/linear.py:116: UserWarning: Deterministic behavior was enabled with either `torch.use_deterministic_algorithms(True)` or `at::Context::setDeterministicAlgorithms(true)`, but this operation is not deterministic because it uses CuBLAS and you have CUDA >= 10.2. To enable deterministic behavior in this case, you must set an environment variable before running your PyTorch application: CUBLAS_WORKSPACE_CONFIG=:4096:8 or CUBLAS_WORKSPACE_CONFIG=:16:8. For more information, go to https://docs.nvidia.com/cuda/cublas/index.html#results-reproducibility (Triggered internally at ../aten/src/ATen/Context.cpp:185.)
return F.linear(input, self.weight, self.bias)===================================================================================================================
Layer (type:depth-idx) Input Shape Output Shape Param #
===================================================================================================================
HittersModel [175, 19] [175] --
├─Flatten: 1-1 [175, 19] [175, 19] --
├─Sequential: 1-2 [175, 19] [175, 1] --
│ └─Linear: 2-1 [175, 19] [175, 50] 1,000
│ └─ReLU: 2-2 [175, 50] [175, 50] --
│ └─Dropout: 2-3 [175, 50] [175, 50] --
│ └─Linear: 2-4 [175, 50] [175, 1] 51
===================================================================================================================
Total params: 1,051
Trainable params: 1,051
Non-trainable params: 0
Total mult-adds (M): 0.18
===================================================================================================================
Input size (MB): 0.01
Forward/backward pass size (MB): 0.07
Params size (MB): 0.00
Estimated Total Size (MB): 0.09
===================================================================================================================We have truncated the end of the output slightly, here and in subsequent uses.
We now need to transform our training data into a form accessible to torch. The basic datatype in torch is a tensor, which is very similar to an ndarray from early chapters. We also note here that torch typically works with 32-bit (single precision) rather than 64-bit (double precision) floating point numbers. We therefore convert our data to np.float32 before forming the tensor. The X and Y tensors are then arranged into a Dataset recognized by torch using TensorDataset().
X_train_t = torch.tensor(X_train.astype(np.float32))
Y_train_t = torch.tensor(Y_train.astype(np.float32))
hit_train = TensorDataset(X_train_t, Y_train_t)We do the same for the test data.
X_test_t = torch.tensor(X_test.astype(np.float32))
Y_test_t = torch.tensor(Y_test.astype(np.float32))
hit_test = TensorDataset(X_test_t, Y_test_t)Finally, this dataset is passed to a DataLoader() which ultimately passes data into our network. While this may seem like a lot of overhead, this structure is helpful for more complex tasks where data may live on different machines, or where data must be passed to a GPU. We provide a helper function SimpleDataModule() in ISLP to make this task easier for standard usage. One of its arguments is num_workers, which indicates how many processes we will use for loading the data. For small data like Hitters this will have little effect, but it does provide an advantage for the MNIST and CIFAR100 examples below. The torch package will inspect the process running and determine a maximum number of workers. {This depends on the computing hardware and the number of cores available.} We’ve included a function rec_num_workers() to compute this so we know how many workers might be reasonable (here the max was 16).
max_num_workers = rec_num_workers()The general training setup in pytorch_lightning involves training, validation and test data. These are each represented by different data loaders. During each epoch, we run a training step to learn the model and a validation step to track the error. The test data is typically used at the end of training to evaluate the model.
In this case, as we had split only into test and training, we’ll use the test data as validation data with the argument validation=hit_test. The validation argument can be a float between 0 and 1, an integer, or a Dataset. If a float (respectively, integer), it is interpreted as a percentage (respectively number) of the training observations to be used for validation. If it is a Dataset, it is passed directly to a data loader.
hit_dm = SimpleDataModule(hit_train,
hit_test,
batch_size=32,
num_workers=min(4, max_num_workers),
validation=hit_test)Next we must provide a pytorch_lightning module that controls the steps performed during the training process. We provide methods for our SimpleModule() that simply record the value of the loss function and any additional metrics at the end of each epoch. These operations are controlled by the methods SimpleModule.[training/test/validation]_step(), though we will not be modifying these in our examples.
hit_module = SimpleModule.regression(hit_model,
metrics={'mae':MeanAbsoluteError()})By using the SimpleModule.regression() method, we indicate that we will use squared-error loss as in (). We have also asked for mean absolute error to be tracked as well in the metrics that are logged.
We log our results via CSVLogger(), which in this case stores the results in a CSV file within a directory logs/hitters. After the fitting is complete, this allows us to load the results as a pd.DataFrame() and visualize them below. There are several ways to log the results within pytorch_lightning, though we will not cover those here in detail.
hit_logger = CSVLogger('logs', name='hitters')Finally we are ready to train our model and log the results. We use the Trainer() object from pytorch_lightning to do this work. The argument datamodule=hit_dm tells the trainer how training/validation/test logs are produced, while the first argument hit_module specifies the network architecture as well as the training/validation/test steps. The callbacks argument allows for several tasks to be carried out at various points while training a model. Here our ErrorTracker() callback will enable us to compute validation error while training and, finally, the test error. We now fit the model for 50 epochs.
hit_trainer = Trainer(deterministic=True,
max_epochs=50,
log_every_n_steps=5,
logger=hit_logger,
callbacks=[ErrorTracker()])
hit_trainer.fit(hit_module, datamodule=hit_dm)GPU available: True (cuda), used: True
TPU available: False, using: 0 TPU cores
IPU available: False, using: 0 IPUs
HPU available: False, using: 0 HPUs
You are using a CUDA device ('NVIDIA GeForce RTX 3070 Laptop GPU') that has Tensor Cores. To properly utilize them, you should set `torch.set_float32_matmul_precision('medium' | 'high')` which will trade-off precision for performance. For more details, read https://pytorch.org/docs/stable/generated/torch.set_float32_matmul_precision.html#torch.set_float32_matmul_precision
LOCAL_RANK: 0 - CUDA_VISIBLE_DEVICES: [0]
| Name | Type | Params
---------------------------------------
0 | model | HittersModel | 1.1 K
1 | loss | MSELoss | 0
---------------------------------------
1.1 K Trainable params
0 Non-trainable params
1.1 K Total params
0.004 Total estimated model params size (MB)Sanity Checking: | | 0/? [00:00<?, ?it/s]--------------------------------------------------------------------------- RuntimeError Traceback (most recent call last) Cell In[27], line 6 1 hit_trainer = Trainer(deterministic=True, 2 max_epochs=50, 3 log_every_n_steps=5, 4 logger=hit_logger, 5 callbacks=[ErrorTracker()]) ----> 6 hit_trainer.fit(hit_module, datamodule=hit_dm) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:544, in Trainer.fit(self, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path) 542 self.state.status = TrainerStatus.RUNNING 543 self.training = True --> 544 call._call_and_handle_interrupt( 545 self, self._fit_impl, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path 546 ) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:44, in _call_and_handle_interrupt(trainer, trainer_fn, *args, **kwargs) 42 if trainer.strategy.launcher is not None: 43 return trainer.strategy.launcher.launch(trainer_fn, *args, trainer=trainer, **kwargs) ---> 44 return trainer_fn(*args, **kwargs) 46 except _TunerExitException: 47 _call_teardown_hook(trainer) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:580, in Trainer._fit_impl(self, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path) 573 assert self.state.fn is not None 574 ckpt_path = self._checkpoint_connector._select_ckpt_path( 575 self.state.fn, 576 ckpt_path, 577 model_provided=True, 578 model_connected=self.lightning_module is not None, 579 ) --> 580 self._run(model, ckpt_path=ckpt_path) 582 assert self.state.stopped 583 self.training = False File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:987, in Trainer._run(self, model, ckpt_path) 982 self._signal_connector.register_signal_handlers() 984 # ---------------------------- 985 # RUN THE TRAINER 986 # ---------------------------- --> 987 results = self._run_stage() 989 # ---------------------------- 990 # POST-Training CLEAN UP 991 # ---------------------------- 992 log.debug(f"{self.__class__.__name__}: trainer tearing down") File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:1031, in Trainer._run_stage(self) 1029 if self.training: 1030 with isolate_rng(): -> 1031 self._run_sanity_check() 1032 with torch.autograd.set_detect_anomaly(self._detect_anomaly): 1033 self.fit_loop.run() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:1060, in Trainer._run_sanity_check(self) 1057 call._call_callback_hooks(self, "on_sanity_check_start") 1059 # run eval step -> 1060 val_loop.run() 1062 call._call_callback_hooks(self, "on_sanity_check_end") 1064 # reset logger connector File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/utilities.py:182, in _no_grad_context.<locals>._decorator(self, *args, **kwargs) 180 context_manager = torch.no_grad 181 with context_manager(): --> 182 return loop_run(self, *args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/evaluation_loop.py:135, in _EvaluationLoop.run(self) 133 self.batch_progress.is_last_batch = data_fetcher.done 134 # run step hooks --> 135 self._evaluation_step(batch, batch_idx, dataloader_idx, dataloader_iter) 136 except StopIteration: 137 # this needs to wrap the `*_step` call too (not just `next`) for `dataloader_iter` support 138 break File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/evaluation_loop.py:385, in _EvaluationLoop._evaluation_step(self, batch, batch_idx, dataloader_idx, dataloader_iter) 380 trainer._logger_connector.on_batch_start( 381 batch, dataloader_idx if self._is_sequential and self.num_dataloaders > 1 else None 382 ) 384 hook_name = "on_test_batch_start" if trainer.testing else "on_validation_batch_start" --> 385 call._call_callback_hooks(trainer, hook_name, *hook_kwargs.values()) 386 call._call_lightning_module_hook(trainer, hook_name, *hook_kwargs.values()) 388 self.batch_progress.increment_started() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:208, in _call_callback_hooks(trainer, hook_name, monitoring_callbacks, *args, **kwargs) 206 if callable(fn): 207 with trainer.profiler.profile(f"[Callback]{callback.state_key}.{hook_name}"): --> 208 fn(trainer, trainer.lightning_module, *args, **kwargs) 210 if pl_module: 211 # restore current_fx when nested context 212 pl_module._current_fx_name = prev_fx_name File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/ISLP/torch/lightning.py:261, in ErrorTracker.on_validation_batch_start(self, trainer, pl_module, batch, batch_idx, dataloader_idx) 254 def on_validation_batch_start(self, 255 trainer, 256 pl_module, 257 batch, 258 batch_idx, 259 dataloader_idx=0): 260 x, y = batch --> 261 self.val_preds.append(pl_module.forward(x)) 262 self.val_targets.append(y) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/ISLP/torch/lightning.py:151, in SimpleModule.forward(self, x) 150 def forward(self, x): --> 151 return self.model(x) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1532, in Module._wrapped_call_impl(self, *args, **kwargs) 1530 return self._compiled_call_impl(*args, **kwargs) # type: ignore[misc] 1531 else: -> 1532 return self._call_impl(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1541, in Module._call_impl(self, *args, **kwargs) 1536 # If we don't have any hooks, we want to skip the rest of the logic in 1537 # this function, and just call forward. 1538 if not (self._backward_hooks or self._backward_pre_hooks or self._forward_hooks or self._forward_pre_hooks 1539 or _global_backward_pre_hooks or _global_backward_hooks 1540 or _global_forward_hooks or _global_forward_pre_hooks): -> 1541 return forward_call(*args, **kwargs) 1543 try: 1544 result = None Cell In[18], line 14, in HittersModel.forward(self, x) 12 def forward(self, x): 13 x = self.flatten(x) ---> 14 return torch.flatten(self.sequential(x)) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1532, in Module._wrapped_call_impl(self, *args, **kwargs) 1530 return self._compiled_call_impl(*args, **kwargs) # type: ignore[misc] 1531 else: -> 1532 return self._call_impl(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1541, in Module._call_impl(self, *args, **kwargs) 1536 # If we don't have any hooks, we want to skip the rest of the logic in 1537 # this function, and just call forward. 1538 if not (self._backward_hooks or self._backward_pre_hooks or self._forward_hooks or self._forward_pre_hooks 1539 or _global_backward_pre_hooks or _global_backward_hooks 1540 or _global_forward_hooks or _global_forward_pre_hooks): -> 1541 return forward_call(*args, **kwargs) 1543 try: 1544 result = None File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/container.py:217, in Sequential.forward(self, input) 215 def forward(self, input): 216 for module in self: --> 217 input = module(input) 218 return input File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1532, in Module._wrapped_call_impl(self, *args, **kwargs) 1530 return self._compiled_call_impl(*args, **kwargs) # type: ignore[misc] 1531 else: -> 1532 return self._call_impl(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1541, in Module._call_impl(self, *args, **kwargs) 1536 # If we don't have any hooks, we want to skip the rest of the logic in 1537 # this function, and just call forward. 1538 if not (self._backward_hooks or self._backward_pre_hooks or self._forward_hooks or self._forward_pre_hooks 1539 or _global_backward_pre_hooks or _global_backward_hooks 1540 or _global_forward_hooks or _global_forward_pre_hooks): -> 1541 return forward_call(*args, **kwargs) 1543 try: 1544 result = None File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/linear.py:116, in Linear.forward(self, input) 115 def forward(self, input: Tensor) -> Tensor: --> 116 return F.linear(input, self.weight, self.bias) RuntimeError: Deterministic behavior was enabled with either `torch.use_deterministic_algorithms(True)` or `at::Context::setDeterministicAlgorithms(true)`, but this operation is not deterministic because it uses CuBLAS and you have CUDA >= 10.2. To enable deterministic behavior in this case, you must set an environment variable before running your PyTorch application: CUBLAS_WORKSPACE_CONFIG=:4096:8 or CUBLAS_WORKSPACE_CONFIG=:16:8. For more information, go to https://docs.nvidia.com/cuda/cublas/index.html#results-reproducibility
At each step of SGD, the algorithm randomly selects 32 training observations for the computation of the gradient. Recall from Section~ that an epoch amounts to the number of SGD steps required to process n observations. Since the training set has n=175, and we specified a batch_size of 32 in the construction of hit_dm, an epoch is 175/32=5.5 SGD steps.
After having fit the model, we can evaluate performance on our test data using the test() method of our trainer.
hit_trainer.test(hit_module, datamodule=hit_dm)LOCAL_RANK: 0 - CUDA_VISIBLE_DEVICES: [0]Testing: | | 0/? [00:00<?, ?it/s]--------------------------------------------------------------------------- RuntimeError Traceback (most recent call last) Cell In[28], line 1 ----> 1 hit_trainer.test(hit_module, datamodule=hit_dm) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:754, in Trainer.test(self, model, dataloaders, ckpt_path, verbose, datamodule) 752 self.state.status = TrainerStatus.RUNNING 753 self.testing = True --> 754 return call._call_and_handle_interrupt( 755 self, self._test_impl, model, dataloaders, ckpt_path, verbose, datamodule 756 ) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:44, in _call_and_handle_interrupt(trainer, trainer_fn, *args, **kwargs) 42 if trainer.strategy.launcher is not None: 43 return trainer.strategy.launcher.launch(trainer_fn, *args, trainer=trainer, **kwargs) ---> 44 return trainer_fn(*args, **kwargs) 46 except _TunerExitException: 47 _call_teardown_hook(trainer) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:794, in Trainer._test_impl(self, model, dataloaders, ckpt_path, verbose, datamodule) 790 assert self.state.fn is not None 791 ckpt_path = self._checkpoint_connector._select_ckpt_path( 792 self.state.fn, ckpt_path, model_provided=model_provided, model_connected=self.lightning_module is not None 793 ) --> 794 results = self._run(model, ckpt_path=ckpt_path) 795 # remove the tensors from the test results 796 results = convert_tensors_to_scalars(results) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:987, in Trainer._run(self, model, ckpt_path) 982 self._signal_connector.register_signal_handlers() 984 # ---------------------------- 985 # RUN THE TRAINER 986 # ---------------------------- --> 987 results = self._run_stage() 989 # ---------------------------- 990 # POST-Training CLEAN UP 991 # ---------------------------- 992 log.debug(f"{self.__class__.__name__}: trainer tearing down") File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:1026, in Trainer._run_stage(self) 1023 self.lightning_module.zero_grad(**zero_grad_kwargs) 1025 if self.evaluating: -> 1026 return self._evaluation_loop.run() 1027 if self.predicting: 1028 return self.predict_loop.run() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/utilities.py:182, in _no_grad_context.<locals>._decorator(self, *args, **kwargs) 180 context_manager = torch.no_grad 181 with context_manager(): --> 182 return loop_run(self, *args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/evaluation_loop.py:135, in _EvaluationLoop.run(self) 133 self.batch_progress.is_last_batch = data_fetcher.done 134 # run step hooks --> 135 self._evaluation_step(batch, batch_idx, dataloader_idx, dataloader_iter) 136 except StopIteration: 137 # this needs to wrap the `*_step` call too (not just `next`) for `dataloader_iter` support 138 break File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/evaluation_loop.py:385, in _EvaluationLoop._evaluation_step(self, batch, batch_idx, dataloader_idx, dataloader_iter) 380 trainer._logger_connector.on_batch_start( 381 batch, dataloader_idx if self._is_sequential and self.num_dataloaders > 1 else None 382 ) 384 hook_name = "on_test_batch_start" if trainer.testing else "on_validation_batch_start" --> 385 call._call_callback_hooks(trainer, hook_name, *hook_kwargs.values()) 386 call._call_lightning_module_hook(trainer, hook_name, *hook_kwargs.values()) 388 self.batch_progress.increment_started() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:208, in _call_callback_hooks(trainer, hook_name, monitoring_callbacks, *args, **kwargs) 206 if callable(fn): 207 with trainer.profiler.profile(f"[Callback]{callback.state_key}.{hook_name}"): --> 208 fn(trainer, trainer.lightning_module, *args, **kwargs) 210 if pl_module: 211 # restore current_fx when nested context 212 pl_module._current_fx_name = prev_fx_name File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/ISLP/torch/lightning.py:297, in ErrorTracker.on_test_batch_start(self, trainer, pl_module, batch, batch_idx, dataloader_idx) 290 def on_test_batch_start(self, 291 trainer, 292 pl_module, 293 batch, 294 batch_idx, 295 dataloader_idx=0): 296 x, y = batch --> 297 self.test_preds.append(pl_module.forward(x)) 298 self.test_targets.append(y) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/ISLP/torch/lightning.py:151, in SimpleModule.forward(self, x) 150 def forward(self, x): --> 151 return self.model(x) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1532, in Module._wrapped_call_impl(self, *args, **kwargs) 1530 return self._compiled_call_impl(*args, **kwargs) # type: ignore[misc] 1531 else: -> 1532 return self._call_impl(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1541, in Module._call_impl(self, *args, **kwargs) 1536 # If we don't have any hooks, we want to skip the rest of the logic in 1537 # this function, and just call forward. 1538 if not (self._backward_hooks or self._backward_pre_hooks or self._forward_hooks or self._forward_pre_hooks 1539 or _global_backward_pre_hooks or _global_backward_hooks 1540 or _global_forward_hooks or _global_forward_pre_hooks): -> 1541 return forward_call(*args, **kwargs) 1543 try: 1544 result = None Cell In[18], line 14, in HittersModel.forward(self, x) 12 def forward(self, x): 13 x = self.flatten(x) ---> 14 return torch.flatten(self.sequential(x)) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1532, in Module._wrapped_call_impl(self, *args, **kwargs) 1530 return self._compiled_call_impl(*args, **kwargs) # type: ignore[misc] 1531 else: -> 1532 return self._call_impl(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1541, in Module._call_impl(self, *args, **kwargs) 1536 # If we don't have any hooks, we want to skip the rest of the logic in 1537 # this function, and just call forward. 1538 if not (self._backward_hooks or self._backward_pre_hooks or self._forward_hooks or self._forward_pre_hooks 1539 or _global_backward_pre_hooks or _global_backward_hooks 1540 or _global_forward_hooks or _global_forward_pre_hooks): -> 1541 return forward_call(*args, **kwargs) 1543 try: 1544 result = None File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/container.py:217, in Sequential.forward(self, input) 215 def forward(self, input): 216 for module in self: --> 217 input = module(input) 218 return input File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1532, in Module._wrapped_call_impl(self, *args, **kwargs) 1530 return self._compiled_call_impl(*args, **kwargs) # type: ignore[misc] 1531 else: -> 1532 return self._call_impl(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1541, in Module._call_impl(self, *args, **kwargs) 1536 # If we don't have any hooks, we want to skip the rest of the logic in 1537 # this function, and just call forward. 1538 if not (self._backward_hooks or self._backward_pre_hooks or self._forward_hooks or self._forward_pre_hooks 1539 or _global_backward_pre_hooks or _global_backward_hooks 1540 or _global_forward_hooks or _global_forward_pre_hooks): -> 1541 return forward_call(*args, **kwargs) 1543 try: 1544 result = None File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/linear.py:116, in Linear.forward(self, input) 115 def forward(self, input: Tensor) -> Tensor: --> 116 return F.linear(input, self.weight, self.bias) RuntimeError: Deterministic behavior was enabled with either `torch.use_deterministic_algorithms(True)` or `at::Context::setDeterministicAlgorithms(true)`, but this operation is not deterministic because it uses CuBLAS and you have CUDA >= 10.2. To enable deterministic behavior in this case, you must set an environment variable before running your PyTorch application: CUBLAS_WORKSPACE_CONFIG=:4096:8 or CUBLAS_WORKSPACE_CONFIG=:16:8. For more information, go to https://docs.nvidia.com/cuda/cublas/index.html#results-reproducibility
The results of the fit have been logged into a CSV file. We can find the results specific to this run in the experiment.metrics_file_path attribute of our logger. Note that each time the model is fit, the logger will output results into a new subdirectory of our directory logs/hitters.
We now create a plot of the MAE (mean absolute error) as a function of the number of epochs. First we retrieve the logged summaries.
hit_results = pd.read_csv(hit_logger.experiment.metrics_file_path)--------------------------------------------------------------------------- FileNotFoundError Traceback (most recent call last) Cell In[29], line 1 ----> 1 hit_results = pd.read_csv(hit_logger.experiment.metrics_file_path) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/parsers/readers.py:1026, in read_csv(filepath_or_buffer, sep, delimiter, header, names, index_col, usecols, dtype, engine, converters, true_values, false_values, skipinitialspace, skiprows, skipfooter, nrows, na_values, keep_default_na, na_filter, verbose, skip_blank_lines, parse_dates, infer_datetime_format, keep_date_col, date_parser, date_format, dayfirst, cache_dates, iterator, chunksize, compression, thousands, decimal, lineterminator, quotechar, quoting, doublequote, escapechar, comment, encoding, encoding_errors, dialect, on_bad_lines, delim_whitespace, low_memory, memory_map, float_precision, storage_options, dtype_backend) 1013 kwds_defaults = _refine_defaults_read( 1014 dialect, 1015 delimiter, (...) 1022 dtype_backend=dtype_backend, 1023 ) 1024 kwds.update(kwds_defaults) -> 1026 return _read(filepath_or_buffer, kwds) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/parsers/readers.py:620, in _read(filepath_or_buffer, kwds) 617 _validate_names(kwds.get("names", None)) 619 # Create the parser. --> 620 parser = TextFileReader(filepath_or_buffer, **kwds) 622 if chunksize or iterator: 623 return parser File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/parsers/readers.py:1620, in TextFileReader.__init__(self, f, engine, **kwds) 1617 self.options["has_index_names"] = kwds["has_index_names"] 1619 self.handles: IOHandles | None = None -> 1620 self._engine = self._make_engine(f, self.engine) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/parsers/readers.py:1880, in TextFileReader._make_engine(self, f, engine) 1878 if "b" not in mode: 1879 mode += "b" -> 1880 self.handles = get_handle( 1881 f, 1882 mode, 1883 encoding=self.options.get("encoding", None), 1884 compression=self.options.get("compression", None), 1885 memory_map=self.options.get("memory_map", False), 1886 is_text=is_text, 1887 errors=self.options.get("encoding_errors", "strict"), 1888 storage_options=self.options.get("storage_options", None), 1889 ) 1890 assert self.handles is not None 1891 f = self.handles.handle File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/common.py:873, in get_handle(path_or_buf, mode, encoding, compression, memory_map, is_text, errors, storage_options) 868 elif isinstance(handle, str): 869 # Check whether the filename is to be opened in binary mode. 870 # Binary mode does not support 'encoding' and 'newline'. 871 if ioargs.encoding and "b" not in ioargs.mode: 872 # Encoding --> 873 handle = open( 874 handle, 875 ioargs.mode, 876 encoding=ioargs.encoding, 877 errors=errors, 878 newline="", 879 ) 880 else: 881 # Binary mode 882 handle = open(handle, ioargs.mode) FileNotFoundError: [Errno 2] No such file or directory: 'logs/hitters/version_1/metrics.csv'
Since we will produce similar plots in later examples, we write a simple generic function to produce this plot.
def summary_plot(results,
ax,
col='loss',
valid_legend='Validation',
training_legend='Training',
ylabel='Loss',
fontsize=20):
for (column,
color,
label) in zip([f'train_{col}_epoch',
f'valid_{col}'],
['black',
'red'],
[training_legend,
valid_legend]):
results.plot(x='epoch',
y=column,
label=label,
marker='o',
color=color,
ax=ax)
ax.set_xlabel('Epoch')
ax.set_ylabel(ylabel)
return axWe now set up our axes, and use our function to produce the MAE plot.
fig, ax = subplots(1, 1, figsize=(6, 6))
ax = summary_plot(hit_results,
ax,
col='mae',
ylabel='MAE',
valid_legend='Validation (=Test)')
ax.set_ylim([0, 400])
ax.set_xticks(np.linspace(0, 50, 11).astype(int));--------------------------------------------------------------------------- NameError Traceback (most recent call last) Cell In[31], line 2 1 fig, ax = subplots(1, 1, figsize=(6, 6)) ----> 2 ax = summary_plot(hit_results, 3 ax, 4 col='mae', 5 ylabel='MAE', 6 valid_legend='Validation (=Test)') 7 ax.set_ylim([0, 400]) 8 ax.set_xticks(np.linspace(0, 50, 11).astype(int)); NameError: name 'hit_results' is not defined
We can predict directly from the final model, and evaluate its performance on the test data. Before fitting, we call the eval() method of hit_model. This tells torch to effectively consider this model to be fitted, so that we can use it to predict on new data. For our model here, the biggest change is that the dropout layers will be turned off, i.e. no weights will be randomly dropped in predicting on new data.
hit_model.eval()
preds = hit_module(X_test_t)
torch.abs(Y_test_t - preds).mean()tensor(711.3991, grad_fn=<MeanBackward0>)Cleanup
In setting up our data module, we had initiated several worker processes that will remain running. We delete all references to the torch objects to ensure these processes will be killed.
del(Hitters,
hit_model, hit_dm,
hit_logger,
hit_test, hit_train,
X, Y,
X_test, X_train,
Y_test, Y_train,
X_test_t, Y_test_t,
hit_trainer, hit_module)Multilayer Network on the MNIST Digit Data
The torchvision package comes with a number of example datasets, including the MNIST digit data. Our first step is to retrieve the training and test data sets; the MNIST() function within torchvision.datasets is provided for this purpose. The data will be downloaded the first time this function is executed, and stored in the directory data/MNIST.
(mnist_train,
mnist_test) = [MNIST(root='data',
train=train,
download=True,
transform=ToTensor())
for train in [True, False]]
mnist_trainDataset MNIST
Number of datapoints: 60000
Root location: data
Split: Train
StandardTransform
Transform: ToTensor()There are 60,000 images in the training data and 10,000 in the test data. The images are 28\times 28, and stored as a matrix of pixels. We need to transform each one into a vector.
Neural networks are somewhat sensitive to the scale of the inputs, much as ridge and lasso regularization are affected by scaling. Here the inputs are eight-bit grayscale values between 0 and 255, so we rescale to the unit interval. {Note: eight bits means 2^8, which equals 256. Since the convention is to start at 0, the possible values range from 0 to 255.} This transformation, along with some reordering of the axes, is performed by the ToTensor() transform from the torchvision.transforms package.
As in our Hitters example, we form a data module from the training and test datasets, setting aside 20% of the training images for validation.
mnist_dm = SimpleDataModule(mnist_train,
mnist_test,
validation=0.2,
num_workers=max_num_workers,
batch_size=256)Let’s take a look at the data that will get fed into our network. We loop through the first few chunks of the test dataset, breaking after 2 batches:
for idx, (X_ ,Y_) in enumerate(mnist_dm.train_dataloader()):
print('X: ', X_.shape)
print('Y: ', Y_.shape)
if idx >= 1:
breakX: torch.Size([256, 1, 28, 28])
Y: torch.Size([256])
X: torch.Size([256, 1, 28, 28])
Y: torch.Size([256])We see that the X for each batch consists of 256 images of size 1x28x28. Here the 1 indicates a single channel (greyscale). For RGB images such as CIFAR100 below, we will see that the 1 in the size will be replaced by 3 for the three RGB channels.
Now we are ready to specify our neural network.
class MNISTModel(nn.Module):
def __init__(self):
super(MNISTModel, self).__init__()
self.layer1 = nn.Sequential(
nn.Flatten(),
nn.Linear(28*28, 256),
nn.ReLU(),
nn.Dropout(0.4))
self.layer2 = nn.Sequential(
nn.Linear(256, 128),
nn.ReLU(),
nn.Dropout(0.3))
self._forward = nn.Sequential(
self.layer1,
self.layer2,
nn.Linear(128, 10))
def forward(self, x):
return self._forward(x)We see that in the first layer, each 1x28x28 image is flattened, then mapped to 256 dimensions where we apply a ReLU activation with 40% dropout. A second layer maps the first layer’s output down to 128 dimensions, applying a ReLU activation with 30% dropout. Finally, the 128 dimensions are mapped down to 10, the number of classes in the MNIST data.
mnist_model = MNISTModel()We can check that the model produces output of expected size based on our existing batch X_ above.
mnist_model(X_).size()torch.Size([256, 10])Let’s take a look at the summary of the model. Instead of an input_size we can pass a tensor of correct shape. In this case, we pass through the final batched X_ from above.
summary(mnist_model,
input_data=X_,
col_names=['input_size',
'output_size',
'num_params'])===================================================================================================================
Layer (type:depth-idx) Input Shape Output Shape Param #
===================================================================================================================
MNISTModel [256, 1, 28, 28] [256, 10] --
├─Sequential: 1-1 [256, 1, 28, 28] [256, 10] --
│ └─Sequential: 2-1 [256, 1, 28, 28] [256, 256] --
│ │ └─Flatten: 3-1 [256, 1, 28, 28] [256, 784] --
│ │ └─Linear: 3-2 [256, 784] [256, 256] 200,960
│ │ └─ReLU: 3-3 [256, 256] [256, 256] --
│ │ └─Dropout: 3-4 [256, 256] [256, 256] --
│ └─Sequential: 2-2 [256, 256] [256, 128] --
│ │ └─Linear: 3-5 [256, 256] [256, 128] 32,896
│ │ └─ReLU: 3-6 [256, 128] [256, 128] --
│ │ └─Dropout: 3-7 [256, 128] [256, 128] --
│ └─Linear: 2-3 [256, 128] [256, 10] 1,290
===================================================================================================================
Total params: 235,146
Trainable params: 235,146
Non-trainable params: 0
Total mult-adds (M): 60.20
===================================================================================================================
Input size (MB): 0.80
Forward/backward pass size (MB): 0.81
Params size (MB): 0.94
Estimated Total Size (MB): 2.55
===================================================================================================================Having set up both the model and the data module, fitting this model is now almost identical to the Hitters example. In contrast to our regression model, here we will use the SimpleModule.classification() method which uses the cross-entropy loss function instead of mean squared error. It must be supplied with the number of classes in the problem.
mnist_module = SimpleModule.classification(mnist_model,
num_classes=10)
mnist_logger = CSVLogger('logs', name='MNIST')Now we are ready to go. The final step is to supply training data, and fit the model. We disable the progress bar below to avoid lengthy output in the browser when running.
mnist_trainer = Trainer(deterministic=True,
max_epochs=30,
logger=mnist_logger,
enable_progress_bar=False,
callbacks=[ErrorTracker()])
mnist_trainer.fit(mnist_module,
datamodule=mnist_dm)GPU available: True (cuda), used: True
TPU available: False, using: 0 TPU cores
IPU available: False, using: 0 IPUs
HPU available: False, using: 0 HPUs
LOCAL_RANK: 0 - CUDA_VISIBLE_DEVICES: [0]
| Name | Type | Params
-------------------------------------------
0 | model | MNISTModel | 235 K
1 | loss | CrossEntropyLoss | 0
-------------------------------------------
235 K Trainable params
0 Non-trainable params
235 K Total params
0.941 Total estimated model params size (MB)--------------------------------------------------------------------------- RuntimeError Traceback (most recent call last) Cell In[42], line 6 1 mnist_trainer = Trainer(deterministic=True, 2 max_epochs=30, 3 logger=mnist_logger, 4 enable_progress_bar=False, 5 callbacks=[ErrorTracker()]) ----> 6 mnist_trainer.fit(mnist_module, 7 datamodule=mnist_dm) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:544, in Trainer.fit(self, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path) 542 self.state.status = TrainerStatus.RUNNING 543 self.training = True --> 544 call._call_and_handle_interrupt( 545 self, self._fit_impl, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path 546 ) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:44, in _call_and_handle_interrupt(trainer, trainer_fn, *args, **kwargs) 42 if trainer.strategy.launcher is not None: 43 return trainer.strategy.launcher.launch(trainer_fn, *args, trainer=trainer, **kwargs) ---> 44 return trainer_fn(*args, **kwargs) 46 except _TunerExitException: 47 _call_teardown_hook(trainer) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:580, in Trainer._fit_impl(self, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path) 573 assert self.state.fn is not None 574 ckpt_path = self._checkpoint_connector._select_ckpt_path( 575 self.state.fn, 576 ckpt_path, 577 model_provided=True, 578 model_connected=self.lightning_module is not None, 579 ) --> 580 self._run(model, ckpt_path=ckpt_path) 582 assert self.state.stopped 583 self.training = False File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:987, in Trainer._run(self, model, ckpt_path) 982 self._signal_connector.register_signal_handlers() 984 # ---------------------------- 985 # RUN THE TRAINER 986 # ---------------------------- --> 987 results = self._run_stage() 989 # ---------------------------- 990 # POST-Training CLEAN UP 991 # ---------------------------- 992 log.debug(f"{self.__class__.__name__}: trainer tearing down") File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:1033, in Trainer._run_stage(self) 1031 self._run_sanity_check() 1032 with torch.autograd.set_detect_anomaly(self._detect_anomaly): -> 1033 self.fit_loop.run() 1034 return None 1035 raise RuntimeError(f"Unexpected state {self.state}") File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/fit_loop.py:205, in _FitLoop.run(self) 203 try: 204 self.on_advance_start() --> 205 self.advance() 206 self.on_advance_end() 207 self._restarting = False File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/fit_loop.py:363, in _FitLoop.advance(self) 361 with self.trainer.profiler.profile("run_training_epoch"): 362 assert self._data_fetcher is not None --> 363 self.epoch_loop.run(self._data_fetcher) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/training_epoch_loop.py:140, in _TrainingEpochLoop.run(self, data_fetcher) 138 while not self.done: 139 try: --> 140 self.advance(data_fetcher) 141 self.on_advance_end(data_fetcher) 142 self._restarting = False File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/training_epoch_loop.py:250, in _TrainingEpochLoop.advance(self, data_fetcher) 247 with trainer.profiler.profile("run_training_batch"): 248 if trainer.lightning_module.automatic_optimization: 249 # in automatic optimization, there can only be one optimizer --> 250 batch_output = self.automatic_optimization.run(trainer.optimizers[0], batch_idx, kwargs) 251 else: 252 batch_output = self.manual_optimization.run(kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/optimization/automatic.py:190, in _AutomaticOptimization.run(self, optimizer, batch_idx, kwargs) 183 closure() 185 # ------------------------------ 186 # BACKWARD PASS 187 # ------------------------------ 188 # gradient update with accumulated gradients 189 else: --> 190 self._optimizer_step(batch_idx, closure) 192 result = closure.consume_result() 193 if result.loss is None: File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/optimization/automatic.py:268, in _AutomaticOptimization._optimizer_step(self, batch_idx, train_step_and_backward_closure) 265 self.optim_progress.optimizer.step.increment_ready() 267 # model hook --> 268 call._call_lightning_module_hook( 269 trainer, 270 "optimizer_step", 271 trainer.current_epoch, 272 batch_idx, 273 optimizer, 274 train_step_and_backward_closure, 275 ) 277 if not should_accumulate: 278 self.optim_progress.optimizer.step.increment_completed() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:157, in _call_lightning_module_hook(trainer, hook_name, pl_module, *args, **kwargs) 154 pl_module._current_fx_name = hook_name 156 with trainer.profiler.profile(f"[LightningModule]{pl_module.__class__.__name__}.{hook_name}"): --> 157 output = fn(*args, **kwargs) 159 # restore current_fx when nested context 160 pl_module._current_fx_name = prev_fx_name File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/core/module.py:1303, in LightningModule.optimizer_step(self, epoch, batch_idx, optimizer, optimizer_closure) 1264 def optimizer_step( 1265 self, 1266 epoch: int, (...) 1269 optimizer_closure: Optional[Callable[[], Any]] = None, 1270 ) -> None: 1271 r"""Override this method to adjust the default way the :class:`~pytorch_lightning.trainer.trainer.Trainer` calls 1272 the optimizer. 1273 (...) 1301 1302 """ -> 1303 optimizer.step(closure=optimizer_closure) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/core/optimizer.py:152, in LightningOptimizer.step(self, closure, **kwargs) 149 raise MisconfigurationException("When `optimizer.step(closure)` is called, the closure should be callable") 151 assert self._strategy is not None --> 152 step_output = self._strategy.optimizer_step(self._optimizer, closure, **kwargs) 154 self._on_after_step() 156 return step_output File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/strategies/strategy.py:239, in Strategy.optimizer_step(self, optimizer, closure, model, **kwargs) 237 # TODO(fabric): remove assertion once strategy's optimizer_step typing is fixed 238 assert isinstance(model, pl.LightningModule) --> 239 return self.precision_plugin.optimizer_step(optimizer, model=model, closure=closure, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/plugins/precision/precision.py:122, in Precision.optimizer_step(self, optimizer, model, closure, **kwargs) 120 """Hook to run the optimizer step.""" 121 closure = partial(self._wrap_closure, model, optimizer, closure) --> 122 return optimizer.step(closure=closure, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/optim/optimizer.py:391, in Optimizer.profile_hook_step.<locals>.wrapper(*args, **kwargs) 386 else: 387 raise RuntimeError( 388 f"{func} must return None or a tuple of (new_args, new_kwargs), but got {result}." 389 ) --> 391 out = func(*args, **kwargs) 392 self._optimizer_step_code() 394 # call optimizer step post hooks File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/optim/optimizer.py:76, in _use_grad_for_differentiable.<locals>._use_grad(self, *args, **kwargs) 74 torch.set_grad_enabled(self.defaults['differentiable']) 75 torch._dynamo.graph_break() ---> 76 ret = func(self, *args, **kwargs) 77 finally: 78 torch._dynamo.graph_break() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/optim/rmsprop.py:109, in RMSprop.step(self, closure) 107 if closure is not None: 108 with torch.enable_grad(): --> 109 loss = closure() 111 for group in self.param_groups: 112 params_with_grad = [] File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/plugins/precision/precision.py:108, in Precision._wrap_closure(self, model, optimizer, closure) 95 def _wrap_closure( 96 self, 97 model: "pl.LightningModule", 98 optimizer: Optimizer, 99 closure: Callable[[], Any], 100 ) -> Any: 101 """This double-closure allows makes sure the ``closure`` is executed before the ``on_before_optimizer_step`` 102 hook is called. 103 (...) 106 107 """ --> 108 closure_result = closure() 109 self._after_closure(model, optimizer) 110 return closure_result File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/optimization/automatic.py:144, in Closure.__call__(self, *args, **kwargs) 142 @override 143 def __call__(self, *args: Any, **kwargs: Any) -> Optional[Tensor]: --> 144 self._result = self.closure(*args, **kwargs) 145 return self._result.loss File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/utils/_contextlib.py:115, in context_decorator.<locals>.decorate_context(*args, **kwargs) 112 @functools.wraps(func) 113 def decorate_context(*args, **kwargs): 114 with ctx_factory(): --> 115 return func(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/optimization/automatic.py:138, in Closure.closure(self, *args, **kwargs) 135 self._zero_grad_fn() 137 if self._backward_fn is not None and step_output.closure_loss is not None: --> 138 self._backward_fn(step_output.closure_loss) 140 return step_output File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/optimization/automatic.py:239, in _AutomaticOptimization._make_backward_fn.<locals>.backward_fn(loss) 238 def backward_fn(loss: Tensor) -> None: --> 239 call._call_strategy_hook(self.trainer, "backward", loss, optimizer) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:309, in _call_strategy_hook(trainer, hook_name, *args, **kwargs) 306 return None 308 with trainer.profiler.profile(f"[Strategy]{trainer.strategy.__class__.__name__}.{hook_name}"): --> 309 output = fn(*args, **kwargs) 311 # restore current_fx when nested context 312 pl_module._current_fx_name = prev_fx_name File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/strategies/strategy.py:213, in Strategy.backward(self, closure_loss, optimizer, *args, **kwargs) 210 assert self.lightning_module is not None 211 closure_loss = self.precision_plugin.pre_backward(closure_loss, self.lightning_module) --> 213 self.precision_plugin.backward(closure_loss, self.lightning_module, optimizer, *args, **kwargs) 215 closure_loss = self.precision_plugin.post_backward(closure_loss, self.lightning_module) 216 self.post_backward(closure_loss) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/plugins/precision/precision.py:72, in Precision.backward(self, tensor, model, optimizer, *args, **kwargs) 52 @override 53 def backward( # type: ignore[override] 54 self, (...) 59 **kwargs: Any, 60 ) -> None: 61 r"""Performs the actual backpropagation. 62 63 Args: (...) 70 71 """ ---> 72 model.backward(tensor, *args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/core/module.py:1090, in LightningModule.backward(self, loss, *args, **kwargs) 1088 self._fabric.backward(loss, *args, **kwargs) 1089 else: -> 1090 loss.backward(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/_tensor.py:525, in Tensor.backward(self, gradient, retain_graph, create_graph, inputs) 515 if has_torch_function_unary(self): 516 return handle_torch_function( 517 Tensor.backward, 518 (self,), (...) 523 inputs=inputs, 524 ) --> 525 torch.autograd.backward( 526 self, gradient, retain_graph, create_graph, inputs=inputs 527 ) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/autograd/__init__.py:267, in backward(tensors, grad_tensors, retain_graph, create_graph, grad_variables, inputs) 262 retain_graph = create_graph 264 # The reason we repeat the same comment below is that 265 # some Python versions print out the first line of a multi-line function 266 # calls in the traceback and some print out the last line --> 267 _engine_run_backward( 268 tensors, 269 grad_tensors_, 270 retain_graph, 271 create_graph, 272 inputs, 273 allow_unreachable=True, 274 accumulate_grad=True, 275 ) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/autograd/graph.py:744, in _engine_run_backward(t_outputs, *args, **kwargs) 742 unregister_hooks = _register_logging_hooks_on_whole_graph(t_outputs) 743 try: --> 744 return Variable._execution_engine.run_backward( # Calls into the C++ engine to run the backward pass 745 t_outputs, *args, **kwargs 746 ) # Calls into the C++ engine to run the backward pass 747 finally: 748 if attach_logging_hooks: RuntimeError: Deterministic behavior was enabled with either `torch.use_deterministic_algorithms(True)` or `at::Context::setDeterministicAlgorithms(true)`, but this operation is not deterministic because it uses CuBLAS and you have CUDA >= 10.2. To enable deterministic behavior in this case, you must set an environment variable before running your PyTorch application: CUBLAS_WORKSPACE_CONFIG=:4096:8 or CUBLAS_WORKSPACE_CONFIG=:16:8. For more information, go to https://docs.nvidia.com/cuda/cublas/index.html#results-reproducibility
We have suppressed the output here, which is a progress report on the fitting of the model, grouped by epoch. This is very useful, since on large datasets fitting can take time. Fitting this model took 245 seconds on a MacBook Pro with an Apple M1 Pro chip with 10 cores and 16 GB of RAM. Here we specified a validation split of 20%, so training is actually performed on 80% of the 60,000 observations in the training set. This is an alternative to actually supplying validation data, like we did for the Hitters data. SGD uses batches of 256 observations in computing the gradient, and doing the arithmetic, we see that an epoch corresponds to 188 gradient steps.
SimpleModule.classification() includes an accuracy metric by default. Other classification metrics can be added from torchmetrics. We will use our summary_plot() function to display accuracy across epochs.
mnist_results = pd.read_csv(mnist_logger.experiment.metrics_file_path)
fig, ax = subplots(1, 1, figsize=(6, 6))
summary_plot(mnist_results,
ax,
col='accuracy',
ylabel='Accuracy')
ax.set_ylim([0.5, 1])
ax.set_ylabel('Accuracy')
ax.set_xticks(np.linspace(0, 30, 7).astype(int));--------------------------------------------------------------------------- FileNotFoundError Traceback (most recent call last) Cell In[43], line 1 ----> 1 mnist_results = pd.read_csv(mnist_logger.experiment.metrics_file_path) 2 fig, ax = subplots(1, 1, figsize=(6, 6)) 3 summary_plot(mnist_results, 4 ax, 5 col='accuracy', 6 ylabel='Accuracy') File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/parsers/readers.py:1026, in read_csv(filepath_or_buffer, sep, delimiter, header, names, index_col, usecols, dtype, engine, converters, true_values, false_values, skipinitialspace, skiprows, skipfooter, nrows, na_values, keep_default_na, na_filter, verbose, skip_blank_lines, parse_dates, infer_datetime_format, keep_date_col, date_parser, date_format, dayfirst, cache_dates, iterator, chunksize, compression, thousands, decimal, lineterminator, quotechar, quoting, doublequote, escapechar, comment, encoding, encoding_errors, dialect, on_bad_lines, delim_whitespace, low_memory, memory_map, float_precision, storage_options, dtype_backend) 1013 kwds_defaults = _refine_defaults_read( 1014 dialect, 1015 delimiter, (...) 1022 dtype_backend=dtype_backend, 1023 ) 1024 kwds.update(kwds_defaults) -> 1026 return _read(filepath_or_buffer, kwds) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/parsers/readers.py:620, in _read(filepath_or_buffer, kwds) 617 _validate_names(kwds.get("names", None)) 619 # Create the parser. --> 620 parser = TextFileReader(filepath_or_buffer, **kwds) 622 if chunksize or iterator: 623 return parser File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/parsers/readers.py:1620, in TextFileReader.__init__(self, f, engine, **kwds) 1617 self.options["has_index_names"] = kwds["has_index_names"] 1619 self.handles: IOHandles | None = None -> 1620 self._engine = self._make_engine(f, self.engine) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/parsers/readers.py:1880, in TextFileReader._make_engine(self, f, engine) 1878 if "b" not in mode: 1879 mode += "b" -> 1880 self.handles = get_handle( 1881 f, 1882 mode, 1883 encoding=self.options.get("encoding", None), 1884 compression=self.options.get("compression", None), 1885 memory_map=self.options.get("memory_map", False), 1886 is_text=is_text, 1887 errors=self.options.get("encoding_errors", "strict"), 1888 storage_options=self.options.get("storage_options", None), 1889 ) 1890 assert self.handles is not None 1891 f = self.handles.handle File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/common.py:873, in get_handle(path_or_buf, mode, encoding, compression, memory_map, is_text, errors, storage_options) 868 elif isinstance(handle, str): 869 # Check whether the filename is to be opened in binary mode. 870 # Binary mode does not support 'encoding' and 'newline'. 871 if ioargs.encoding and "b" not in ioargs.mode: 872 # Encoding --> 873 handle = open( 874 handle, 875 ioargs.mode, 876 encoding=ioargs.encoding, 877 errors=errors, 878 newline="", 879 ) 880 else: 881 # Binary mode 882 handle = open(handle, ioargs.mode) FileNotFoundError: [Errno 2] No such file or directory: 'logs/MNIST/version_1/metrics.csv'
Once again we evaluate the accuracy using the test() method of our trainer. This model achieves 97% accuracy on the test data.
mnist_trainer.test(mnist_module,
datamodule=mnist_dm)LOCAL_RANK: 0 - CUDA_VISIBLE_DEVICES: [0]────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────
Test metric DataLoader 0
────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────
test_accuracy 0.08829999715089798
test_loss 2.305781841278076
────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────[{'test_loss': 2.305781841278076, 'test_accuracy': 0.08829999715089798}]Table~ also reports the error rates resulting from LDA (Chapter~) and multiclass logistic regression. For LDA we refer the reader to Section~. Although we could use the sklearn function LogisticRegression() to fit
multiclass logistic regression, we are set up here to fit such a model with torch. We just have an input layer and an output layer, and omit the hidden layers!
class MNIST_MLR(nn.Module):
def __init__(self):
super(MNIST_MLR, self).__init__()
self.linear = nn.Sequential(nn.Flatten(),
nn.Linear(784, 10))
def forward(self, x):
return self.linear(x)
mlr_model = MNIST_MLR()
mlr_module = SimpleModule.classification(mlr_model,
num_classes=10)
mlr_logger = CSVLogger('logs', name='MNIST_MLR')mlr_trainer = Trainer(deterministic=True,
max_epochs=30,
enable_progress_bar=False,
callbacks=[ErrorTracker()])
mlr_trainer.fit(mlr_module, datamodule=mnist_dm)GPU available: True (cuda), used: True
TPU available: False, using: 0 TPU cores
IPU available: False, using: 0 IPUs
HPU available: False, using: 0 HPUs
/home/oren/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/connectors/logger_connector/logger_connector.py:75: Starting from v1.9.0, `tensorboardX` has been removed as a dependency of the `pytorch_lightning` package, due to potential conflicts with other packages in the ML ecosystem. For this reason, `logger=True` will use `CSVLogger` as the default logger, unless the `tensorboard` or `tensorboardX` packages are found. Please `pip install lightning[extra]` or one of them to enable TensorBoard support by default
LOCAL_RANK: 0 - CUDA_VISIBLE_DEVICES: [0]
| Name | Type | Params
-------------------------------------------
0 | model | MNIST_MLR | 7.9 K
1 | loss | CrossEntropyLoss | 0
-------------------------------------------
7.9 K Trainable params
0 Non-trainable params
7.9 K Total params
0.031 Total estimated model params size (MB)--------------------------------------------------------------------------- RuntimeError Traceback (most recent call last) Cell In[46], line 5 1 mlr_trainer = Trainer(deterministic=True, 2 max_epochs=30, 3 enable_progress_bar=False, 4 callbacks=[ErrorTracker()]) ----> 5 mlr_trainer.fit(mlr_module, datamodule=mnist_dm) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:544, in Trainer.fit(self, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path) 542 self.state.status = TrainerStatus.RUNNING 543 self.training = True --> 544 call._call_and_handle_interrupt( 545 self, self._fit_impl, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path 546 ) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:44, in _call_and_handle_interrupt(trainer, trainer_fn, *args, **kwargs) 42 if trainer.strategy.launcher is not None: 43 return trainer.strategy.launcher.launch(trainer_fn, *args, trainer=trainer, **kwargs) ---> 44 return trainer_fn(*args, **kwargs) 46 except _TunerExitException: 47 _call_teardown_hook(trainer) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:580, in Trainer._fit_impl(self, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path) 573 assert self.state.fn is not None 574 ckpt_path = self._checkpoint_connector._select_ckpt_path( 575 self.state.fn, 576 ckpt_path, 577 model_provided=True, 578 model_connected=self.lightning_module is not None, 579 ) --> 580 self._run(model, ckpt_path=ckpt_path) 582 assert self.state.stopped 583 self.training = False File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:987, in Trainer._run(self, model, ckpt_path) 982 self._signal_connector.register_signal_handlers() 984 # ---------------------------- 985 # RUN THE TRAINER 986 # ---------------------------- --> 987 results = self._run_stage() 989 # ---------------------------- 990 # POST-Training CLEAN UP 991 # ---------------------------- 992 log.debug(f"{self.__class__.__name__}: trainer tearing down") File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:1033, in Trainer._run_stage(self) 1031 self._run_sanity_check() 1032 with torch.autograd.set_detect_anomaly(self._detect_anomaly): -> 1033 self.fit_loop.run() 1034 return None 1035 raise RuntimeError(f"Unexpected state {self.state}") File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/fit_loop.py:205, in _FitLoop.run(self) 203 try: 204 self.on_advance_start() --> 205 self.advance() 206 self.on_advance_end() 207 self._restarting = False File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/fit_loop.py:363, in _FitLoop.advance(self) 361 with self.trainer.profiler.profile("run_training_epoch"): 362 assert self._data_fetcher is not None --> 363 self.epoch_loop.run(self._data_fetcher) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/training_epoch_loop.py:140, in _TrainingEpochLoop.run(self, data_fetcher) 138 while not self.done: 139 try: --> 140 self.advance(data_fetcher) 141 self.on_advance_end(data_fetcher) 142 self._restarting = False File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/training_epoch_loop.py:250, in _TrainingEpochLoop.advance(self, data_fetcher) 247 with trainer.profiler.profile("run_training_batch"): 248 if trainer.lightning_module.automatic_optimization: 249 # in automatic optimization, there can only be one optimizer --> 250 batch_output = self.automatic_optimization.run(trainer.optimizers[0], batch_idx, kwargs) 251 else: 252 batch_output = self.manual_optimization.run(kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/optimization/automatic.py:190, in _AutomaticOptimization.run(self, optimizer, batch_idx, kwargs) 183 closure() 185 # ------------------------------ 186 # BACKWARD PASS 187 # ------------------------------ 188 # gradient update with accumulated gradients 189 else: --> 190 self._optimizer_step(batch_idx, closure) 192 result = closure.consume_result() 193 if result.loss is None: File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/optimization/automatic.py:268, in _AutomaticOptimization._optimizer_step(self, batch_idx, train_step_and_backward_closure) 265 self.optim_progress.optimizer.step.increment_ready() 267 # model hook --> 268 call._call_lightning_module_hook( 269 trainer, 270 "optimizer_step", 271 trainer.current_epoch, 272 batch_idx, 273 optimizer, 274 train_step_and_backward_closure, 275 ) 277 if not should_accumulate: 278 self.optim_progress.optimizer.step.increment_completed() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:157, in _call_lightning_module_hook(trainer, hook_name, pl_module, *args, **kwargs) 154 pl_module._current_fx_name = hook_name 156 with trainer.profiler.profile(f"[LightningModule]{pl_module.__class__.__name__}.{hook_name}"): --> 157 output = fn(*args, **kwargs) 159 # restore current_fx when nested context 160 pl_module._current_fx_name = prev_fx_name File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/core/module.py:1303, in LightningModule.optimizer_step(self, epoch, batch_idx, optimizer, optimizer_closure) 1264 def optimizer_step( 1265 self, 1266 epoch: int, (...) 1269 optimizer_closure: Optional[Callable[[], Any]] = None, 1270 ) -> None: 1271 r"""Override this method to adjust the default way the :class:`~pytorch_lightning.trainer.trainer.Trainer` calls 1272 the optimizer. 1273 (...) 1301 1302 """ -> 1303 optimizer.step(closure=optimizer_closure) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/core/optimizer.py:152, in LightningOptimizer.step(self, closure, **kwargs) 149 raise MisconfigurationException("When `optimizer.step(closure)` is called, the closure should be callable") 151 assert self._strategy is not None --> 152 step_output = self._strategy.optimizer_step(self._optimizer, closure, **kwargs) 154 self._on_after_step() 156 return step_output File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/strategies/strategy.py:239, in Strategy.optimizer_step(self, optimizer, closure, model, **kwargs) 237 # TODO(fabric): remove assertion once strategy's optimizer_step typing is fixed 238 assert isinstance(model, pl.LightningModule) --> 239 return self.precision_plugin.optimizer_step(optimizer, model=model, closure=closure, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/plugins/precision/precision.py:122, in Precision.optimizer_step(self, optimizer, model, closure, **kwargs) 120 """Hook to run the optimizer step.""" 121 closure = partial(self._wrap_closure, model, optimizer, closure) --> 122 return optimizer.step(closure=closure, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/optim/optimizer.py:391, in Optimizer.profile_hook_step.<locals>.wrapper(*args, **kwargs) 386 else: 387 raise RuntimeError( 388 f"{func} must return None or a tuple of (new_args, new_kwargs), but got {result}." 389 ) --> 391 out = func(*args, **kwargs) 392 self._optimizer_step_code() 394 # call optimizer step post hooks File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/optim/optimizer.py:76, in _use_grad_for_differentiable.<locals>._use_grad(self, *args, **kwargs) 74 torch.set_grad_enabled(self.defaults['differentiable']) 75 torch._dynamo.graph_break() ---> 76 ret = func(self, *args, **kwargs) 77 finally: 78 torch._dynamo.graph_break() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/optim/rmsprop.py:109, in RMSprop.step(self, closure) 107 if closure is not None: 108 with torch.enable_grad(): --> 109 loss = closure() 111 for group in self.param_groups: 112 params_with_grad = [] File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/plugins/precision/precision.py:108, in Precision._wrap_closure(self, model, optimizer, closure) 95 def _wrap_closure( 96 self, 97 model: "pl.LightningModule", 98 optimizer: Optimizer, 99 closure: Callable[[], Any], 100 ) -> Any: 101 """This double-closure allows makes sure the ``closure`` is executed before the ``on_before_optimizer_step`` 102 hook is called. 103 (...) 106 107 """ --> 108 closure_result = closure() 109 self._after_closure(model, optimizer) 110 return closure_result File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/optimization/automatic.py:144, in Closure.__call__(self, *args, **kwargs) 142 @override 143 def __call__(self, *args: Any, **kwargs: Any) -> Optional[Tensor]: --> 144 self._result = self.closure(*args, **kwargs) 145 return self._result.loss File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/utils/_contextlib.py:115, in context_decorator.<locals>.decorate_context(*args, **kwargs) 112 @functools.wraps(func) 113 def decorate_context(*args, **kwargs): 114 with ctx_factory(): --> 115 return func(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/optimization/automatic.py:138, in Closure.closure(self, *args, **kwargs) 135 self._zero_grad_fn() 137 if self._backward_fn is not None and step_output.closure_loss is not None: --> 138 self._backward_fn(step_output.closure_loss) 140 return step_output File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/optimization/automatic.py:239, in _AutomaticOptimization._make_backward_fn.<locals>.backward_fn(loss) 238 def backward_fn(loss: Tensor) -> None: --> 239 call._call_strategy_hook(self.trainer, "backward", loss, optimizer) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:309, in _call_strategy_hook(trainer, hook_name, *args, **kwargs) 306 return None 308 with trainer.profiler.profile(f"[Strategy]{trainer.strategy.__class__.__name__}.{hook_name}"): --> 309 output = fn(*args, **kwargs) 311 # restore current_fx when nested context 312 pl_module._current_fx_name = prev_fx_name File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/strategies/strategy.py:213, in Strategy.backward(self, closure_loss, optimizer, *args, **kwargs) 210 assert self.lightning_module is not None 211 closure_loss = self.precision_plugin.pre_backward(closure_loss, self.lightning_module) --> 213 self.precision_plugin.backward(closure_loss, self.lightning_module, optimizer, *args, **kwargs) 215 closure_loss = self.precision_plugin.post_backward(closure_loss, self.lightning_module) 216 self.post_backward(closure_loss) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/plugins/precision/precision.py:72, in Precision.backward(self, tensor, model, optimizer, *args, **kwargs) 52 @override 53 def backward( # type: ignore[override] 54 self, (...) 59 **kwargs: Any, 60 ) -> None: 61 r"""Performs the actual backpropagation. 62 63 Args: (...) 70 71 """ ---> 72 model.backward(tensor, *args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/core/module.py:1090, in LightningModule.backward(self, loss, *args, **kwargs) 1088 self._fabric.backward(loss, *args, **kwargs) 1089 else: -> 1090 loss.backward(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/_tensor.py:525, in Tensor.backward(self, gradient, retain_graph, create_graph, inputs) 515 if has_torch_function_unary(self): 516 return handle_torch_function( 517 Tensor.backward, 518 (self,), (...) 523 inputs=inputs, 524 ) --> 525 torch.autograd.backward( 526 self, gradient, retain_graph, create_graph, inputs=inputs 527 ) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/autograd/__init__.py:267, in backward(tensors, grad_tensors, retain_graph, create_graph, grad_variables, inputs) 262 retain_graph = create_graph 264 # The reason we repeat the same comment below is that 265 # some Python versions print out the first line of a multi-line function 266 # calls in the traceback and some print out the last line --> 267 _engine_run_backward( 268 tensors, 269 grad_tensors_, 270 retain_graph, 271 create_graph, 272 inputs, 273 allow_unreachable=True, 274 accumulate_grad=True, 275 ) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/autograd/graph.py:744, in _engine_run_backward(t_outputs, *args, **kwargs) 742 unregister_hooks = _register_logging_hooks_on_whole_graph(t_outputs) 743 try: --> 744 return Variable._execution_engine.run_backward( # Calls into the C++ engine to run the backward pass 745 t_outputs, *args, **kwargs 746 ) # Calls into the C++ engine to run the backward pass 747 finally: 748 if attach_logging_hooks: RuntimeError: Deterministic behavior was enabled with either `torch.use_deterministic_algorithms(True)` or `at::Context::setDeterministicAlgorithms(true)`, but this operation is not deterministic because it uses CuBLAS and you have CUDA >= 10.2. To enable deterministic behavior in this case, you must set an environment variable before running your PyTorch application: CUBLAS_WORKSPACE_CONFIG=:4096:8 or CUBLAS_WORKSPACE_CONFIG=:16:8. For more information, go to https://docs.nvidia.com/cuda/cublas/index.html#results-reproducibility
We fit the model just as before and compute the test results.
mlr_trainer.test(mlr_module,
datamodule=mnist_dm)LOCAL_RANK: 0 - CUDA_VISIBLE_DEVICES: [0]────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────
Test metric DataLoader 0
────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────
test_accuracy 0.05660000070929527
test_loss 2.34493350982666
────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────[{'test_loss': 2.34493350982666, 'test_accuracy': 0.05660000070929527}]The accuracy is above 90% even for this pretty simple model.
As in the Hitters example, we delete some of the objects we created above.
del(mnist_test,
mnist_train,
mnist_model,
mnist_dm,
mnist_trainer,
mnist_module,
mnist_results,
mlr_model,
mlr_module,
mlr_trainer)--------------------------------------------------------------------------- NameError Traceback (most recent call last) Cell In[48], line 7 1 del(mnist_test, 2 mnist_train, 3 mnist_model, 4 mnist_dm, 5 mnist_trainer, 6 mnist_module, ----> 7 mnist_results, 8 mlr_model, 9 mlr_module, 10 mlr_trainer) NameError: name 'mnist_results' is not defined
Convolutional Neural Networks
In this section we fit a CNN to the CIFAR100 data, which is available in the torchvision package. It is arranged in a similar fashion as the MNIST data.
(cifar_train,
cifar_test) = [CIFAR100(root="data",
train=train,
download=True)
for train in [True, False]]Files already downloaded and verified
Files already downloaded and verifiedtransform = ToTensor()
cifar_train_X = torch.stack([transform(x) for x in
cifar_train.data])
cifar_test_X = torch.stack([transform(x) for x in
cifar_test.data])
cifar_train = TensorDataset(cifar_train_X,
torch.tensor(cifar_train.targets))
cifar_test = TensorDataset(cifar_test_X,
torch.tensor(cifar_test.targets)) Testing: | | 0/? [00:05<?, ?it/s]The CIFAR100 dataset consists of 50,000 training images, each represented by a three-dimensional tensor: each three-color image is represented as a set of three channels, each of which consists of 32\times 32 eight-bit pixels. We standardize as we did for the digits, but keep the array structure. This is accomplished with the ToTensor() transform.
Creating the data module is similar to the MNIST example.
cifar_dm = SimpleDataModule(cifar_train,
cifar_test,
validation=0.2,
num_workers=max_num_workers,
batch_size=128)We again look at the shape of typical batches in our data loaders.
for idx, (X_ ,Y_) in enumerate(cifar_dm.train_dataloader()):
print('X: ', X_.shape)
print('Y: ', Y_.shape)
if idx >= 1:
breakX: torch.Size([128, 3, 32, 32])
Y: torch.Size([128])
X: torch.Size([128, 3, 32, 32])
Y: torch.Size([128])Before we start, we look at some of the training images; similar code produced Figure~ on page . The example below also illustrates that TensorDataset objects can be indexed with integers — we are choosing random images from the training data by indexing cifar_train. In order to display correctly, we must reorder the dimensions by a call to np.transpose().
fig, axes = subplots(5, 5, figsize=(10,10))
rng = np.random.default_rng(4)
indices = rng.choice(np.arange(len(cifar_train)), 25,
replace=False).reshape((5,5))
for i in range(5):
for j in range(5):
idx = indices[i,j]
axes[i,j].imshow(np.transpose(cifar_train[idx][0],
[1,2,0]),
interpolation=None)
axes[i,j].set_xticks([])
axes[i,j].set_yticks([])
Here the imshow() method recognizes from the shape of its argument that it is a 3-dimensional array, with the last dimension indexing the three RGB color channels.
We specify a moderately-sized CNN for demonstration purposes, similar in structure to Figure~. We use several layers, each consisting of convolution, ReLU, and max-pooling steps. We first define a module that defines one of these layers. As in our previous examples, we overwrite the __init__() and forward() methods of nn.Module. This user-defined module can now be used in ways just like nn.Linear() or nn.Dropout().
class BuildingBlock(nn.Module):
def __init__(self,
in_channels,
out_channels):
super(BuildingBlock, self).__init__()
self.conv = nn.Conv2d(in_channels=in_channels,
out_channels=out_channels,
kernel_size=(3,3),
padding='same')
self.activation = nn.ReLU()
self.pool = nn.MaxPool2d(kernel_size=(2,2))
def forward(self, x):
return self.pool(self.activation(self.conv(x)))Notice that we used the padding = "same" argument to nn.Conv2d(), which ensures that the output channels have the same dimension as the input channels. There are 32 channels in the first hidden layer, in contrast to the three channels in the input layer. We use a 3\times 3 convolution filter for each channel in all the layers. Each convolution is followed by a max-pooling layer over 2\times2 blocks.
In forming our deep learning model for the CIFAR100 data, we use several of our BuildingBlock() modules sequentially. This simple example illustrates some of the power of torch. Users can define modules of their own, which can be combined in other modules. Ultimately, everything is fit by a generic trainer.
class CIFARModel(nn.Module):
def __init__(self):
super(CIFARModel, self).__init__()
sizes = [(3,32),
(32,64),
(64,128),
(128,256)]
self.conv = nn.Sequential(*[BuildingBlock(in_, out_)
for in_, out_ in sizes])
self.output = nn.Sequential(nn.Dropout(0.5),
nn.Linear(2*2*256, 512),
nn.ReLU(),
nn.Linear(512, 100))
def forward(self, x):
val = self.conv(x)
val = torch.flatten(val, start_dim=1)
return self.output(val)We build the model and look at the summary. (We had created examples of X_ earlier.)
cifar_model = CIFARModel()
summary(cifar_model,
input_data=X_,
col_names=['input_size',
'output_size',
'num_params'])===================================================================================================================
Layer (type:depth-idx) Input Shape Output Shape Param #
===================================================================================================================
CIFARModel [128, 3, 32, 32] [128, 100] --
├─Sequential: 1-1 [128, 3, 32, 32] [128, 256, 2, 2] --
│ └─BuildingBlock: 2-1 [128, 3, 32, 32] [128, 32, 16, 16] --
│ │ └─Conv2d: 3-1 [128, 3, 32, 32] [128, 32, 32, 32] 896
│ │ └─ReLU: 3-2 [128, 32, 32, 32] [128, 32, 32, 32] --
│ │ └─MaxPool2d: 3-3 [128, 32, 32, 32] [128, 32, 16, 16] --
│ └─BuildingBlock: 2-2 [128, 32, 16, 16] [128, 64, 8, 8] --
│ │ └─Conv2d: 3-4 [128, 32, 16, 16] [128, 64, 16, 16] 18,496
│ │ └─ReLU: 3-5 [128, 64, 16, 16] [128, 64, 16, 16] --
│ │ └─MaxPool2d: 3-6 [128, 64, 16, 16] [128, 64, 8, 8] --
│ └─BuildingBlock: 2-3 [128, 64, 8, 8] [128, 128, 4, 4] --
│ │ └─Conv2d: 3-7 [128, 64, 8, 8] [128, 128, 8, 8] 73,856
│ │ └─ReLU: 3-8 [128, 128, 8, 8] [128, 128, 8, 8] --
│ │ └─MaxPool2d: 3-9 [128, 128, 8, 8] [128, 128, 4, 4] --
│ └─BuildingBlock: 2-4 [128, 128, 4, 4] [128, 256, 2, 2] --
│ │ └─Conv2d: 3-10 [128, 128, 4, 4] [128, 256, 4, 4] 295,168
│ │ └─ReLU: 3-11 [128, 256, 4, 4] [128, 256, 4, 4] --
│ │ └─MaxPool2d: 3-12 [128, 256, 4, 4] [128, 256, 2, 2] --
├─Sequential: 1-2 [128, 1024] [128, 100] --
│ └─Dropout: 2-5 [128, 1024] [128, 1024] --
│ └─Linear: 2-6 [128, 1024] [128, 512] 524,800
│ └─ReLU: 2-7 [128, 512] [128, 512] --
│ └─Linear: 2-8 [128, 512] [128, 100] 51,300
===================================================================================================================
Total params: 964,516
Trainable params: 964,516
Non-trainable params: 0
Total mult-adds (G): 2.01
===================================================================================================================
Input size (MB): 1.57
Forward/backward pass size (MB): 63.54
Params size (MB): 3.86
Estimated Total Size (MB): 68.97
===================================================================================================================The total number of trainable parameters is 964,516. By studying the size of the parameters, we can see that the channels halve in both dimensions after each of these max-pooling operations. After the last of these we have a layer with 256 channels of dimension 2\times 2. These are then flattened to a dense layer of size 1,024; in other words, each of the 2\times 2 matrices is turned into a 4-vector, and put side-by-side in one layer. This is followed by a dropout regularization layer, then another dense layer of size 512, and finally, the output layer.
Up to now, we have been using a default optimizer in SimpleModule(). For these data, experiments show that a smaller learning rate performs better than the default 0.01. We use a custom optimizer here with a learning rate of 0.001. Besides this, the logging and training follow a similar pattern to our previous examples. The optimizer takes an argument params that informs the optimizer which parameters are involved in SGD (stochastic gradient descent).
We saw earlier that entries of a module’s parameters are tensors. In passing the parameters to the optimizer we are doing more than simply passing arrays; part of the structure of the graph is encoded in the tensors themselves.
cifar_optimizer = RMSprop(cifar_model.parameters(), lr=0.001)
cifar_module = SimpleModule.classification(cifar_model,
num_classes=100,
optimizer=cifar_optimizer)
cifar_logger = CSVLogger('logs', name='CIFAR100')cifar_trainer = Trainer(deterministic=True,
max_epochs=30,
logger=cifar_logger,
enable_progress_bar=False,
callbacks=[ErrorTracker()])
cifar_trainer.fit(cifar_module,
datamodule=cifar_dm)GPU available: True (cuda), used: True
TPU available: False, using: 0 TPU cores
IPU available: False, using: 0 IPUs
HPU available: False, using: 0 HPUs
Missing logger folder: logs/CIFAR100
LOCAL_RANK: 0 - CUDA_VISIBLE_DEVICES: [0]
| Name | Type | Params
-------------------------------------------
0 | model | CIFARModel | 964 K
1 | loss | CrossEntropyLoss | 0
-------------------------------------------
964 K Trainable params
0 Non-trainable params
964 K Total params
3.858 Total estimated model params size (MB)--------------------------------------------------------------------------- RuntimeError Traceback (most recent call last) Cell In[58], line 6 1 cifar_trainer = Trainer(deterministic=True, 2 max_epochs=30, 3 logger=cifar_logger, 4 enable_progress_bar=False, 5 callbacks=[ErrorTracker()]) ----> 6 cifar_trainer.fit(cifar_module, 7 datamodule=cifar_dm) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:544, in Trainer.fit(self, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path) 542 self.state.status = TrainerStatus.RUNNING 543 self.training = True --> 544 call._call_and_handle_interrupt( 545 self, self._fit_impl, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path 546 ) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:44, in _call_and_handle_interrupt(trainer, trainer_fn, *args, **kwargs) 42 if trainer.strategy.launcher is not None: 43 return trainer.strategy.launcher.launch(trainer_fn, *args, trainer=trainer, **kwargs) ---> 44 return trainer_fn(*args, **kwargs) 46 except _TunerExitException: 47 _call_teardown_hook(trainer) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:580, in Trainer._fit_impl(self, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path) 573 assert self.state.fn is not None 574 ckpt_path = self._checkpoint_connector._select_ckpt_path( 575 self.state.fn, 576 ckpt_path, 577 model_provided=True, 578 model_connected=self.lightning_module is not None, 579 ) --> 580 self._run(model, ckpt_path=ckpt_path) 582 assert self.state.stopped 583 self.training = False File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:987, in Trainer._run(self, model, ckpt_path) 982 self._signal_connector.register_signal_handlers() 984 # ---------------------------- 985 # RUN THE TRAINER 986 # ---------------------------- --> 987 results = self._run_stage() 989 # ---------------------------- 990 # POST-Training CLEAN UP 991 # ---------------------------- 992 log.debug(f"{self.__class__.__name__}: trainer tearing down") File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:1033, in Trainer._run_stage(self) 1031 self._run_sanity_check() 1032 with torch.autograd.set_detect_anomaly(self._detect_anomaly): -> 1033 self.fit_loop.run() 1034 return None 1035 raise RuntimeError(f"Unexpected state {self.state}") File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/fit_loop.py:205, in _FitLoop.run(self) 203 try: 204 self.on_advance_start() --> 205 self.advance() 206 self.on_advance_end() 207 self._restarting = False File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/fit_loop.py:363, in _FitLoop.advance(self) 361 with self.trainer.profiler.profile("run_training_epoch"): 362 assert self._data_fetcher is not None --> 363 self.epoch_loop.run(self._data_fetcher) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/training_epoch_loop.py:140, in _TrainingEpochLoop.run(self, data_fetcher) 138 while not self.done: 139 try: --> 140 self.advance(data_fetcher) 141 self.on_advance_end(data_fetcher) 142 self._restarting = False File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/training_epoch_loop.py:250, in _TrainingEpochLoop.advance(self, data_fetcher) 247 with trainer.profiler.profile("run_training_batch"): 248 if trainer.lightning_module.automatic_optimization: 249 # in automatic optimization, there can only be one optimizer --> 250 batch_output = self.automatic_optimization.run(trainer.optimizers[0], batch_idx, kwargs) 251 else: 252 batch_output = self.manual_optimization.run(kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/optimization/automatic.py:190, in _AutomaticOptimization.run(self, optimizer, batch_idx, kwargs) 183 closure() 185 # ------------------------------ 186 # BACKWARD PASS 187 # ------------------------------ 188 # gradient update with accumulated gradients 189 else: --> 190 self._optimizer_step(batch_idx, closure) 192 result = closure.consume_result() 193 if result.loss is None: File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/optimization/automatic.py:268, in _AutomaticOptimization._optimizer_step(self, batch_idx, train_step_and_backward_closure) 265 self.optim_progress.optimizer.step.increment_ready() 267 # model hook --> 268 call._call_lightning_module_hook( 269 trainer, 270 "optimizer_step", 271 trainer.current_epoch, 272 batch_idx, 273 optimizer, 274 train_step_and_backward_closure, 275 ) 277 if not should_accumulate: 278 self.optim_progress.optimizer.step.increment_completed() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:157, in _call_lightning_module_hook(trainer, hook_name, pl_module, *args, **kwargs) 154 pl_module._current_fx_name = hook_name 156 with trainer.profiler.profile(f"[LightningModule]{pl_module.__class__.__name__}.{hook_name}"): --> 157 output = fn(*args, **kwargs) 159 # restore current_fx when nested context 160 pl_module._current_fx_name = prev_fx_name File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/core/module.py:1303, in LightningModule.optimizer_step(self, epoch, batch_idx, optimizer, optimizer_closure) 1264 def optimizer_step( 1265 self, 1266 epoch: int, (...) 1269 optimizer_closure: Optional[Callable[[], Any]] = None, 1270 ) -> None: 1271 r"""Override this method to adjust the default way the :class:`~pytorch_lightning.trainer.trainer.Trainer` calls 1272 the optimizer. 1273 (...) 1301 1302 """ -> 1303 optimizer.step(closure=optimizer_closure) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/core/optimizer.py:152, in LightningOptimizer.step(self, closure, **kwargs) 149 raise MisconfigurationException("When `optimizer.step(closure)` is called, the closure should be callable") 151 assert self._strategy is not None --> 152 step_output = self._strategy.optimizer_step(self._optimizer, closure, **kwargs) 154 self._on_after_step() 156 return step_output File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/strategies/strategy.py:239, in Strategy.optimizer_step(self, optimizer, closure, model, **kwargs) 237 # TODO(fabric): remove assertion once strategy's optimizer_step typing is fixed 238 assert isinstance(model, pl.LightningModule) --> 239 return self.precision_plugin.optimizer_step(optimizer, model=model, closure=closure, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/plugins/precision/precision.py:122, in Precision.optimizer_step(self, optimizer, model, closure, **kwargs) 120 """Hook to run the optimizer step.""" 121 closure = partial(self._wrap_closure, model, optimizer, closure) --> 122 return optimizer.step(closure=closure, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/optim/optimizer.py:391, in Optimizer.profile_hook_step.<locals>.wrapper(*args, **kwargs) 386 else: 387 raise RuntimeError( 388 f"{func} must return None or a tuple of (new_args, new_kwargs), but got {result}." 389 ) --> 391 out = func(*args, **kwargs) 392 self._optimizer_step_code() 394 # call optimizer step post hooks File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/optim/optimizer.py:76, in _use_grad_for_differentiable.<locals>._use_grad(self, *args, **kwargs) 74 torch.set_grad_enabled(self.defaults['differentiable']) 75 torch._dynamo.graph_break() ---> 76 ret = func(self, *args, **kwargs) 77 finally: 78 torch._dynamo.graph_break() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/optim/rmsprop.py:109, in RMSprop.step(self, closure) 107 if closure is not None: 108 with torch.enable_grad(): --> 109 loss = closure() 111 for group in self.param_groups: 112 params_with_grad = [] File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/plugins/precision/precision.py:108, in Precision._wrap_closure(self, model, optimizer, closure) 95 def _wrap_closure( 96 self, 97 model: "pl.LightningModule", 98 optimizer: Optimizer, 99 closure: Callable[[], Any], 100 ) -> Any: 101 """This double-closure allows makes sure the ``closure`` is executed before the ``on_before_optimizer_step`` 102 hook is called. 103 (...) 106 107 """ --> 108 closure_result = closure() 109 self._after_closure(model, optimizer) 110 return closure_result File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/optimization/automatic.py:144, in Closure.__call__(self, *args, **kwargs) 142 @override 143 def __call__(self, *args: Any, **kwargs: Any) -> Optional[Tensor]: --> 144 self._result = self.closure(*args, **kwargs) 145 return self._result.loss File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/utils/_contextlib.py:115, in context_decorator.<locals>.decorate_context(*args, **kwargs) 112 @functools.wraps(func) 113 def decorate_context(*args, **kwargs): 114 with ctx_factory(): --> 115 return func(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/optimization/automatic.py:138, in Closure.closure(self, *args, **kwargs) 135 self._zero_grad_fn() 137 if self._backward_fn is not None and step_output.closure_loss is not None: --> 138 self._backward_fn(step_output.closure_loss) 140 return step_output File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/optimization/automatic.py:239, in _AutomaticOptimization._make_backward_fn.<locals>.backward_fn(loss) 238 def backward_fn(loss: Tensor) -> None: --> 239 call._call_strategy_hook(self.trainer, "backward", loss, optimizer) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:309, in _call_strategy_hook(trainer, hook_name, *args, **kwargs) 306 return None 308 with trainer.profiler.profile(f"[Strategy]{trainer.strategy.__class__.__name__}.{hook_name}"): --> 309 output = fn(*args, **kwargs) 311 # restore current_fx when nested context 312 pl_module._current_fx_name = prev_fx_name File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/strategies/strategy.py:213, in Strategy.backward(self, closure_loss, optimizer, *args, **kwargs) 210 assert self.lightning_module is not None 211 closure_loss = self.precision_plugin.pre_backward(closure_loss, self.lightning_module) --> 213 self.precision_plugin.backward(closure_loss, self.lightning_module, optimizer, *args, **kwargs) 215 closure_loss = self.precision_plugin.post_backward(closure_loss, self.lightning_module) 216 self.post_backward(closure_loss) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/plugins/precision/precision.py:72, in Precision.backward(self, tensor, model, optimizer, *args, **kwargs) 52 @override 53 def backward( # type: ignore[override] 54 self, (...) 59 **kwargs: Any, 60 ) -> None: 61 r"""Performs the actual backpropagation. 62 63 Args: (...) 70 71 """ ---> 72 model.backward(tensor, *args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/core/module.py:1090, in LightningModule.backward(self, loss, *args, **kwargs) 1088 self._fabric.backward(loss, *args, **kwargs) 1089 else: -> 1090 loss.backward(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/_tensor.py:525, in Tensor.backward(self, gradient, retain_graph, create_graph, inputs) 515 if has_torch_function_unary(self): 516 return handle_torch_function( 517 Tensor.backward, 518 (self,), (...) 523 inputs=inputs, 524 ) --> 525 torch.autograd.backward( 526 self, gradient, retain_graph, create_graph, inputs=inputs 527 ) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/autograd/__init__.py:267, in backward(tensors, grad_tensors, retain_graph, create_graph, grad_variables, inputs) 262 retain_graph = create_graph 264 # The reason we repeat the same comment below is that 265 # some Python versions print out the first line of a multi-line function 266 # calls in the traceback and some print out the last line --> 267 _engine_run_backward( 268 tensors, 269 grad_tensors_, 270 retain_graph, 271 create_graph, 272 inputs, 273 allow_unreachable=True, 274 accumulate_grad=True, 275 ) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/autograd/graph.py:744, in _engine_run_backward(t_outputs, *args, **kwargs) 742 unregister_hooks = _register_logging_hooks_on_whole_graph(t_outputs) 743 try: --> 744 return Variable._execution_engine.run_backward( # Calls into the C++ engine to run the backward pass 745 t_outputs, *args, **kwargs 746 ) # Calls into the C++ engine to run the backward pass 747 finally: 748 if attach_logging_hooks: RuntimeError: Deterministic behavior was enabled with either `torch.use_deterministic_algorithms(True)` or `at::Context::setDeterministicAlgorithms(true)`, but this operation is not deterministic because it uses CuBLAS and you have CUDA >= 10.2. To enable deterministic behavior in this case, you must set an environment variable before running your PyTorch application: CUBLAS_WORKSPACE_CONFIG=:4096:8 or CUBLAS_WORKSPACE_CONFIG=:16:8. For more information, go to https://docs.nvidia.com/cuda/cublas/index.html#results-reproducibility
This model can take 10 minutes or more to run and achieves about 42% accuracy on the test data. Although this is not terrible for 100-class data (a random classifier gets 1% accuracy), searching the web we see results around 75%. Typically it takes a lot of architecture carpentry, fiddling with regularization, and time, to achieve such results.
Let’s take a look at the validation and training accuracy across epochs.
log_path = cifar_logger.experiment.metrics_file_path
cifar_results = pd.read_csv(log_path)
fig, ax = subplots(1, 1, figsize=(6, 6))
summary_plot(cifar_results,
ax,
col='accuracy',
ylabel='Accuracy')
ax.set_xticks(np.linspace(0, 10, 6).astype(int))
ax.set_ylabel('Accuracy')
ax.set_ylim([0, 1]);--------------------------------------------------------------------------- FileNotFoundError Traceback (most recent call last) Cell In[59], line 2 1 log_path = cifar_logger.experiment.metrics_file_path ----> 2 cifar_results = pd.read_csv(log_path) 3 fig, ax = subplots(1, 1, figsize=(6, 6)) 4 summary_plot(cifar_results, 5 ax, 6 col='accuracy', 7 ylabel='Accuracy') File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/parsers/readers.py:1026, in read_csv(filepath_or_buffer, sep, delimiter, header, names, index_col, usecols, dtype, engine, converters, true_values, false_values, skipinitialspace, skiprows, skipfooter, nrows, na_values, keep_default_na, na_filter, verbose, skip_blank_lines, parse_dates, infer_datetime_format, keep_date_col, date_parser, date_format, dayfirst, cache_dates, iterator, chunksize, compression, thousands, decimal, lineterminator, quotechar, quoting, doublequote, escapechar, comment, encoding, encoding_errors, dialect, on_bad_lines, delim_whitespace, low_memory, memory_map, float_precision, storage_options, dtype_backend) 1013 kwds_defaults = _refine_defaults_read( 1014 dialect, 1015 delimiter, (...) 1022 dtype_backend=dtype_backend, 1023 ) 1024 kwds.update(kwds_defaults) -> 1026 return _read(filepath_or_buffer, kwds) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/parsers/readers.py:620, in _read(filepath_or_buffer, kwds) 617 _validate_names(kwds.get("names", None)) 619 # Create the parser. --> 620 parser = TextFileReader(filepath_or_buffer, **kwds) 622 if chunksize or iterator: 623 return parser File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/parsers/readers.py:1620, in TextFileReader.__init__(self, f, engine, **kwds) 1617 self.options["has_index_names"] = kwds["has_index_names"] 1619 self.handles: IOHandles | None = None -> 1620 self._engine = self._make_engine(f, self.engine) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/parsers/readers.py:1880, in TextFileReader._make_engine(self, f, engine) 1878 if "b" not in mode: 1879 mode += "b" -> 1880 self.handles = get_handle( 1881 f, 1882 mode, 1883 encoding=self.options.get("encoding", None), 1884 compression=self.options.get("compression", None), 1885 memory_map=self.options.get("memory_map", False), 1886 is_text=is_text, 1887 errors=self.options.get("encoding_errors", "strict"), 1888 storage_options=self.options.get("storage_options", None), 1889 ) 1890 assert self.handles is not None 1891 f = self.handles.handle File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/common.py:873, in get_handle(path_or_buf, mode, encoding, compression, memory_map, is_text, errors, storage_options) 868 elif isinstance(handle, str): 869 # Check whether the filename is to be opened in binary mode. 870 # Binary mode does not support 'encoding' and 'newline'. 871 if ioargs.encoding and "b" not in ioargs.mode: 872 # Encoding --> 873 handle = open( 874 handle, 875 ioargs.mode, 876 encoding=ioargs.encoding, 877 errors=errors, 878 newline="", 879 ) 880 else: 881 # Binary mode 882 handle = open(handle, ioargs.mode) FileNotFoundError: [Errno 2] No such file or directory: 'logs/CIFAR100/version_0/metrics.csv'
Finally, we evaluate our model on our test data.
cifar_trainer.test(cifar_module,
datamodule=cifar_dm)LOCAL_RANK: 0 - CUDA_VISIBLE_DEVICES: [0]────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────
Test metric DataLoader 0
────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────
test_accuracy 0.010900000110268593
test_loss 4.6055097579956055
────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────[{'test_loss': 4.6055097579956055, 'test_accuracy': 0.010900000110268593}]Hardware Acceleration
As deep learning has become ubiquitous in machine learning, hardware manufacturers have produced special libraries that can often speed up the gradient-descent steps.
For instance, Mac OS devices with the M1 chip may have the Metal programming framework enabled, which can speed up the torch computations. We present an example of how to use this acceleration.
The main changes are to the Trainer() call as well as to the metrics that will be evaluated on the data. These metrics must be told where the data will be located at evaluation time. This is accomplished with a call to the to() method of the metrics.
try:
for name, metric in cifar_module.metrics.items():
cifar_module.metrics[name] = metric.to('mps')
cifar_trainer_mps = Trainer(accelerator='mps',
deterministic=True,
enable_progress_bar=False,
max_epochs=30)
cifar_trainer_mps.fit(cifar_module,
datamodule=cifar_dm)
cifar_trainer_mps.test(cifar_module,
datamodule=cifar_dm)
except:
passThis yields approximately two- or three-fold acceleration for each epoch. We have protected this code block using try: and except: clauses; if it works, we get the speedup, if it fails, nothing happens.
Using Pretrained CNN Models
We now show how to use a CNN pretrained on the imagenet database to classify natural images, and demonstrate how we produced Figure~. We copied six JPEG images from a digital photo album into the directory book_images. These images are available from the data section of <www.statlearning.com>, the ISLP book website. Download book_images.zip; when clicked it creates the book_images directory.
The pretrained network we use is called resnet50; specification details can be found on the web. We will read in the images, and convert them into the array format expected by the torch software to match the specifications in resnet50. The conversion involves a resize, a crop and then a predefined standardization for each of the three channels. We now read in the images and preprocess them.
resize = Resize((232,232), antialias=True)
crop = CenterCrop(224)
normalize = Normalize([0.485,0.456,0.406],
[0.229,0.224,0.225])
imgfiles = sorted([f for f in glob('book_images/*')])
imgs = torch.stack([torch.div(crop(resize(read_image(f))), 255)
for f in imgfiles])
imgs = normalize(imgs)
imgs.size()--------------------------------------------------------------------------- RuntimeError Traceback (most recent call last) Cell In[62], line 6 3 normalize = Normalize([0.485,0.456,0.406], 4 [0.229,0.224,0.225]) 5 imgfiles = sorted([f for f in glob('book_images/*')]) ----> 6 imgs = torch.stack([torch.div(crop(resize(read_image(f))), 255) 7 for f in imgfiles]) 8 imgs = normalize(imgs) 9 imgs.size() RuntimeError: stack expects a non-empty TensorList
We now set up the trained network with the weights we read in code block~6. The model has 50 layers, with a fair bit of complexity.
resnet_model = resnet50(weights=ResNet50_Weights.DEFAULT)
summary(resnet_model,
input_data=imgs,
col_names=['input_size',
'output_size',
'num_params'])--------------------------------------------------------------------------- NameError Traceback (most recent call last) Cell In[63], line 3 1 resnet_model = resnet50(weights=ResNet50_Weights.DEFAULT) 2 summary(resnet_model, ----> 3 input_data=imgs, 4 col_names=['input_size', 5 'output_size', 6 'num_params']) NameError: name 'imgs' is not defined
We set the mode to eval() to ensure that the model is ready to predict on new data.
resnet_model.eval()ResNet(
(conv1): Conv2d(3, 64, kernel_size=(7, 7), stride=(2, 2), padding=(3, 3), bias=False)
(bn1): BatchNorm2d(64, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(relu): ReLU(inplace=True)
(maxpool): MaxPool2d(kernel_size=3, stride=2, padding=1, dilation=1, ceil_mode=False)
(layer1): Sequential(
(0): Bottleneck(
(conv1): Conv2d(64, 64, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn1): BatchNorm2d(64, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv2): Conv2d(64, 64, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1), bias=False)
(bn2): BatchNorm2d(64, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv3): Conv2d(64, 256, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn3): BatchNorm2d(256, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(relu): ReLU(inplace=True)
(downsample): Sequential(
(0): Conv2d(64, 256, kernel_size=(1, 1), stride=(1, 1), bias=False)
(1): BatchNorm2d(256, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
)
)
(1): Bottleneck(
(conv1): Conv2d(256, 64, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn1): BatchNorm2d(64, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv2): Conv2d(64, 64, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1), bias=False)
(bn2): BatchNorm2d(64, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv3): Conv2d(64, 256, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn3): BatchNorm2d(256, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(relu): ReLU(inplace=True)
)
(2): Bottleneck(
(conv1): Conv2d(256, 64, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn1): BatchNorm2d(64, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv2): Conv2d(64, 64, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1), bias=False)
(bn2): BatchNorm2d(64, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv3): Conv2d(64, 256, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn3): BatchNorm2d(256, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(relu): ReLU(inplace=True)
)
)
(layer2): Sequential(
(0): Bottleneck(
(conv1): Conv2d(256, 128, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn1): BatchNorm2d(128, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv2): Conv2d(128, 128, kernel_size=(3, 3), stride=(2, 2), padding=(1, 1), bias=False)
(bn2): BatchNorm2d(128, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv3): Conv2d(128, 512, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn3): BatchNorm2d(512, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(relu): ReLU(inplace=True)
(downsample): Sequential(
(0): Conv2d(256, 512, kernel_size=(1, 1), stride=(2, 2), bias=False)
(1): BatchNorm2d(512, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
)
)
(1): Bottleneck(
(conv1): Conv2d(512, 128, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn1): BatchNorm2d(128, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv2): Conv2d(128, 128, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1), bias=False)
(bn2): BatchNorm2d(128, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv3): Conv2d(128, 512, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn3): BatchNorm2d(512, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(relu): ReLU(inplace=True)
)
(2): Bottleneck(
(conv1): Conv2d(512, 128, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn1): BatchNorm2d(128, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv2): Conv2d(128, 128, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1), bias=False)
(bn2): BatchNorm2d(128, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv3): Conv2d(128, 512, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn3): BatchNorm2d(512, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(relu): ReLU(inplace=True)
)
(3): Bottleneck(
(conv1): Conv2d(512, 128, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn1): BatchNorm2d(128, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv2): Conv2d(128, 128, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1), bias=False)
(bn2): BatchNorm2d(128, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv3): Conv2d(128, 512, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn3): BatchNorm2d(512, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(relu): ReLU(inplace=True)
)
)
(layer3): Sequential(
(0): Bottleneck(
(conv1): Conv2d(512, 256, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn1): BatchNorm2d(256, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv2): Conv2d(256, 256, kernel_size=(3, 3), stride=(2, 2), padding=(1, 1), bias=False)
(bn2): BatchNorm2d(256, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv3): Conv2d(256, 1024, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn3): BatchNorm2d(1024, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(relu): ReLU(inplace=True)
(downsample): Sequential(
(0): Conv2d(512, 1024, kernel_size=(1, 1), stride=(2, 2), bias=False)
(1): BatchNorm2d(1024, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
)
)
(1): Bottleneck(
(conv1): Conv2d(1024, 256, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn1): BatchNorm2d(256, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv2): Conv2d(256, 256, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1), bias=False)
(bn2): BatchNorm2d(256, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv3): Conv2d(256, 1024, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn3): BatchNorm2d(1024, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(relu): ReLU(inplace=True)
)
(2): Bottleneck(
(conv1): Conv2d(1024, 256, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn1): BatchNorm2d(256, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv2): Conv2d(256, 256, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1), bias=False)
(bn2): BatchNorm2d(256, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv3): Conv2d(256, 1024, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn3): BatchNorm2d(1024, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(relu): ReLU(inplace=True)
)
(3): Bottleneck(
(conv1): Conv2d(1024, 256, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn1): BatchNorm2d(256, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv2): Conv2d(256, 256, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1), bias=False)
(bn2): BatchNorm2d(256, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv3): Conv2d(256, 1024, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn3): BatchNorm2d(1024, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(relu): ReLU(inplace=True)
)
(4): Bottleneck(
(conv1): Conv2d(1024, 256, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn1): BatchNorm2d(256, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv2): Conv2d(256, 256, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1), bias=False)
(bn2): BatchNorm2d(256, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv3): Conv2d(256, 1024, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn3): BatchNorm2d(1024, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(relu): ReLU(inplace=True)
)
(5): Bottleneck(
(conv1): Conv2d(1024, 256, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn1): BatchNorm2d(256, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv2): Conv2d(256, 256, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1), bias=False)
(bn2): BatchNorm2d(256, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv3): Conv2d(256, 1024, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn3): BatchNorm2d(1024, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(relu): ReLU(inplace=True)
)
)
(layer4): Sequential(
(0): Bottleneck(
(conv1): Conv2d(1024, 512, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn1): BatchNorm2d(512, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv2): Conv2d(512, 512, kernel_size=(3, 3), stride=(2, 2), padding=(1, 1), bias=False)
(bn2): BatchNorm2d(512, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv3): Conv2d(512, 2048, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn3): BatchNorm2d(2048, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(relu): ReLU(inplace=True)
(downsample): Sequential(
(0): Conv2d(1024, 2048, kernel_size=(1, 1), stride=(2, 2), bias=False)
(1): BatchNorm2d(2048, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
)
)
(1): Bottleneck(
(conv1): Conv2d(2048, 512, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn1): BatchNorm2d(512, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv2): Conv2d(512, 512, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1), bias=False)
(bn2): BatchNorm2d(512, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv3): Conv2d(512, 2048, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn3): BatchNorm2d(2048, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(relu): ReLU(inplace=True)
)
(2): Bottleneck(
(conv1): Conv2d(2048, 512, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn1): BatchNorm2d(512, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv2): Conv2d(512, 512, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1), bias=False)
(bn2): BatchNorm2d(512, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(conv3): Conv2d(512, 2048, kernel_size=(1, 1), stride=(1, 1), bias=False)
(bn3): BatchNorm2d(2048, eps=1e-05, momentum=0.1, affine=True, track_running_stats=True)
(relu): ReLU(inplace=True)
)
)
(avgpool): AdaptiveAvgPool2d(output_size=(1, 1))
(fc): Linear(in_features=2048, out_features=1000, bias=True)
)Inspecting the output above, we see that when setting up the resnet_model, the authors defined a Bottleneck, much like our BuildingBlock module.
We now feed our six images through the fitted network.
img_preds = resnet_model(imgs)--------------------------------------------------------------------------- NameError Traceback (most recent call last) Cell In[65], line 1 ----> 1 img_preds = resnet_model(imgs) NameError: name 'imgs' is not defined
Let’s look at the predicted probabilities for each of the top 3 choices. First we compute the probabilities by applying the softmax to the logits in img_preds. Note that we have had to call the detach() method on the tensor img_preds in order to convert it to our a more familiar ndarray.
img_probs = np.exp(np.asarray(img_preds.detach()))
img_probs /= img_probs.sum(1)[:,None]--------------------------------------------------------------------------- NameError Traceback (most recent call last) Cell In[66], line 1 ----> 1 img_probs = np.exp(np.asarray(img_preds.detach())) 2 img_probs /= img_probs.sum(1)[:,None] NameError: name 'img_preds' is not defined
In order to see the class labels, we must download the index file associated with imagenet. {This is avalable from the book website and s3.amazonaws.com/deep-learning-models/image-models/imagenet_class_index.json.}
labs = json.load(open('imagenet_class_index.json'))
class_labels = pd.DataFrame([(int(k), v[1]) for k, v in
labs.items()],
columns=['idx', 'label'])
class_labels = class_labels.set_index('idx')
class_labels = class_labels.sort_index()--------------------------------------------------------------------------- FileNotFoundError Traceback (most recent call last) Cell In[67], line 1 ----> 1 labs = json.load(open('imagenet_class_index.json')) 2 class_labels = pd.DataFrame([(int(k), v[1]) for k, v in 3 labs.items()], 4 columns=['idx', 'label']) 5 class_labels = class_labels.set_index('idx') File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/IPython/core/interactiveshell.py:324, in _modified_open(file, *args, **kwargs) 317 if file in {0, 1, 2}: 318 raise ValueError( 319 f"IPython won't let you open fd={file} by default " 320 "as it is likely to crash IPython. If you know what you are doing, " 321 "you can use builtins' open." 322 ) --> 324 return io_open(file, *args, **kwargs) FileNotFoundError: [Errno 2] No such file or directory: 'imagenet_class_index.json'
We’ll now construct a data frame for each image file with the labels with the three highest probabilities as estimated by the model above.
for i, imgfile in enumerate(imgfiles):
img_df = class_labels.copy()
img_df['prob'] = img_probs[i]
img_df = img_df.sort_values(by='prob', ascending=False)[:3]
print(f'Image: {imgfile}')
print(img_df.reset_index().drop(columns=['idx']))We see that the model is quite confident about Flamingo.jpg, but a little less so for the other images.
We end this section with our usual cleanup.
del(cifar_test,
cifar_train,
cifar_dm,
cifar_module,
cifar_logger,
cifar_optimizer,
cifar_trainer)IMDB Document Classification
We now implement models for sentiment classification (Section~) on the IMDB dataset. As mentioned above code block~8, we are using a preprocessed version of the IMDB dataset found in the keras package. As keras uses tensorflow, a different tensor and deep learning library, we have converted the data to be suitable for torch. The code used to convert from keras is available in the module ISLP.torch._make_imdb. It requires some of the keras packages to run. These data use a dictionary of size 10,000.
We have stored three different representations of the review data for this lab:
load_tensor(), a sparse tensor version usable bytorch;load_sparse(), a sparse matrix version usable bysklearn, since we will compare with a lasso fit;load_sequential(), a padded version of the original sequence representation, limited to the last 500 words of each review.
(imdb_seq_train,
imdb_seq_test) = load_sequential(root='data/IMDB')
padded_sample = np.asarray(imdb_seq_train.tensors[0][0])
sample_review = padded_sample[padded_sample > 0][:12]
sample_review[:12]Retrieving "IMDB_S_train.tensor.gz" from "http://imdb.jtaylor.su.domains/jtaylor/data/".
Retrieving "IMDB_S_test.tensor.gz" from "http://imdb.jtaylor.su.domains/jtaylor/data/".
Retrieving "IMDB_Y_test.npy" from "http://imdb.jtaylor.su.domains/jtaylor/data/".
Retrieving "IMDB_Y_train.npy" from "http://imdb.jtaylor.su.domains/jtaylor/data/".array([ 1, 14, 22, 16, 43, 530, 973, 1622, 1385, 65, 458,
4468], dtype=int32)The datasets imdb_seq_train and imdb_seq_test are both instances of the class TensorDataset. The tensors used to construct them can be found in the tensors attribute, with the first tensor the features X and the second the outcome Y. We have taken the first row of features and stored it as padded_sample. In the preprocessing used to form these data, sequences were padded with 0s in the beginning if they were not long enough, hence we remove this padding by restricting to entries where padded_sample > 0. We then provide the first 12 words of the sample review.
We can find these words in the lookup dictionary from the ISLP.torch.imdb module.
lookup = load_lookup(root='data/IMDB')
' '.join(lookup[i] for i in sample_review)Retrieving "IMDB_word_index.pkl" from "http://imdb.jtaylor.su.domains/jtaylor/data/"."<START> this film was just brilliant casting location scenery story direction everyone's"For our first model, we have created a binary feature for each of the 10,000 possible words in the dataset, with an entry of one in the i,j entry if word j appears in review i. As most reviews are quite short, such a feature matrix has over 98% zeros. These data are accessed using load_tensor() from the ISLP library.
max_num_workers=10
(imdb_train,
imdb_test) = load_tensor(root='data/IMDB')
imdb_dm = SimpleDataModule(imdb_train,
imdb_test,
validation=2000,
num_workers=min(6, max_num_workers),
batch_size=512)Retrieving "IMDB_X_test.tensor.gz" from "http://imdb.jtaylor.su.domains/jtaylor/data/".
Retrieving "IMDB_X_train.tensor.gz" from "http://imdb.jtaylor.su.domains/jtaylor/data/".We’ll use a two-layer model for our first model.
class IMDBModel(nn.Module):
def __init__(self, input_size):
super(IMDBModel, self).__init__()
self.dense1 = nn.Linear(input_size, 16)
self.activation = nn.ReLU()
self.dense2 = nn.Linear(16, 16)
self.output = nn.Linear(16, 1)
def forward(self, x):
val = x
for _map in [self.dense1,
self.activation,
self.dense2,
self.activation,
self.output]:
val = _map(val)
return torch.flatten(val)We now instantiate our model and look at a summary.
imdb_model = IMDBModel(imdb_test.tensors[0].size()[1])
summary(imdb_model,
input_size=imdb_test.tensors[0].size(),
col_names=['input_size',
'output_size',
'num_params'])--------------------------------------------------------------------------- RuntimeError Traceback (most recent call last) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torchinfo/torchinfo.py:295, in forward_pass(model, x, batch_dim, cache_forward_pass, device, mode, **kwargs) 294 if isinstance(x, (list, tuple)): --> 295 _ = model(*x, **kwargs) 296 elif isinstance(x, dict): File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1532, in Module._wrapped_call_impl(self, *args, **kwargs) 1531 else: -> 1532 return self._call_impl(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1582, in Module._call_impl(self, *args, **kwargs) 1580 args = bw_hook.setup_input_hook(args) -> 1582 result = forward_call(*args, **kwargs) 1583 if _global_forward_hooks or self._forward_hooks: Cell In[73], line 17, in IMDBModel.forward(self, x) 12 for _map in [self.dense1, 13 self.activation, 14 self.dense2, 15 self.activation, 16 self.output]: ---> 17 val = _map(val) 18 return torch.flatten(val) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1532, in Module._wrapped_call_impl(self, *args, **kwargs) 1531 else: -> 1532 return self._call_impl(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1582, in Module._call_impl(self, *args, **kwargs) 1580 args = bw_hook.setup_input_hook(args) -> 1582 result = forward_call(*args, **kwargs) 1583 if _global_forward_hooks or self._forward_hooks: File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/linear.py:116, in Linear.forward(self, input) 115 def forward(self, input: Tensor) -> Tensor: --> 116 return F.linear(input, self.weight, self.bias) RuntimeError: Deterministic behavior was enabled with either `torch.use_deterministic_algorithms(True)` or `at::Context::setDeterministicAlgorithms(true)`, but this operation is not deterministic because it uses CuBLAS and you have CUDA >= 10.2. To enable deterministic behavior in this case, you must set an environment variable before running your PyTorch application: CUBLAS_WORKSPACE_CONFIG=:4096:8 or CUBLAS_WORKSPACE_CONFIG=:16:8. For more information, go to https://docs.nvidia.com/cuda/cublas/index.html#results-reproducibility The above exception was the direct cause of the following exception: RuntimeError Traceback (most recent call last) Cell In[74], line 2 1 imdb_model = IMDBModel(imdb_test.tensors[0].size()[1]) ----> 2 summary(imdb_model, 3 input_size=imdb_test.tensors[0].size(), 4 col_names=['input_size', 5 'output_size', 6 'num_params']) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torchinfo/torchinfo.py:223, in summary(model, input_size, input_data, batch_dim, cache_forward_pass, col_names, col_width, depth, device, dtypes, mode, row_settings, verbose, **kwargs) 216 validate_user_params( 217 input_data, input_size, columns, col_width, device, dtypes, verbose 218 ) 220 x, correct_input_size = process_input( 221 input_data, input_size, batch_dim, device, dtypes 222 ) --> 223 summary_list = forward_pass( 224 model, x, batch_dim, cache_forward_pass, device, model_mode, **kwargs 225 ) 226 formatting = FormattingOptions(depth, verbose, columns, col_width, rows) 227 results = ModelStatistics( 228 summary_list, correct_input_size, get_total_memory_used(x), formatting 229 ) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torchinfo/torchinfo.py:304, in forward_pass(model, x, batch_dim, cache_forward_pass, device, mode, **kwargs) 302 except Exception as e: 303 executed_layers = [layer for layer in summary_list if layer.executed] --> 304 raise RuntimeError( 305 "Failed to run torchinfo. See above stack traces for more details. " 306 f"Executed layers up to: {executed_layers}" 307 ) from e 308 finally: 309 if hooks: RuntimeError: Failed to run torchinfo. See above stack traces for more details. Executed layers up to: [Linear: 1, ReLU: 1, Linear: 1, ReLU: 1]
We’ll again use a smaller learning rate for these data, hence we pass an optimizer to the SimpleModule. Since the reviews are classified into positive or negative sentiment, we use SimpleModule.binary_classification(). {Our use of binary_classification() instead of classification() is due to some subtlety in how torchmetrics.Accuracy() works, as well as the data type of the targets.}
imdb_optimizer = RMSprop(imdb_model.parameters(), lr=0.001)
imdb_module = SimpleModule.binary_classification(
imdb_model,
optimizer=imdb_optimizer)Having loaded the datasets into a data module and created a SimpleModule, the remaining steps are familiar.
imdb_logger = CSVLogger('logs', name='IMDB')
imdb_trainer = Trainer(deterministic=True,
max_epochs=30,
logger=imdb_logger,
enable_progress_bar=False,
callbacks=[ErrorTracker()])
imdb_trainer.fit(imdb_module,
datamodule=imdb_dm)GPU available: True (cuda), used: True
TPU available: False, using: 0 TPU cores
IPU available: False, using: 0 IPUs
HPU available: False, using: 0 HPUs
Missing logger folder: logs/IMDB
LOCAL_RANK: 0 - CUDA_VISIBLE_DEVICES: [0]
| Name | Type | Params
--------------------------------------------
0 | model | IMDBModel | 160 K
1 | loss | BCEWithLogitsLoss | 0
--------------------------------------------
160 K Trainable params
0 Non-trainable params
160 K Total params
0.641 Total estimated model params size (MB)--------------------------------------------------------------------------- RuntimeError Traceback (most recent call last) Cell In[76], line 7 1 imdb_logger = CSVLogger('logs', name='IMDB') 2 imdb_trainer = Trainer(deterministic=True, 3 max_epochs=30, 4 logger=imdb_logger, 5 enable_progress_bar=False, 6 callbacks=[ErrorTracker()]) ----> 7 imdb_trainer.fit(imdb_module, 8 datamodule=imdb_dm) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:544, in Trainer.fit(self, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path) 542 self.state.status = TrainerStatus.RUNNING 543 self.training = True --> 544 call._call_and_handle_interrupt( 545 self, self._fit_impl, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path 546 ) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:44, in _call_and_handle_interrupt(trainer, trainer_fn, *args, **kwargs) 42 if trainer.strategy.launcher is not None: 43 return trainer.strategy.launcher.launch(trainer_fn, *args, trainer=trainer, **kwargs) ---> 44 return trainer_fn(*args, **kwargs) 46 except _TunerExitException: 47 _call_teardown_hook(trainer) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:580, in Trainer._fit_impl(self, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path) 573 assert self.state.fn is not None 574 ckpt_path = self._checkpoint_connector._select_ckpt_path( 575 self.state.fn, 576 ckpt_path, 577 model_provided=True, 578 model_connected=self.lightning_module is not None, 579 ) --> 580 self._run(model, ckpt_path=ckpt_path) 582 assert self.state.stopped 583 self.training = False File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:987, in Trainer._run(self, model, ckpt_path) 982 self._signal_connector.register_signal_handlers() 984 # ---------------------------- 985 # RUN THE TRAINER 986 # ---------------------------- --> 987 results = self._run_stage() 989 # ---------------------------- 990 # POST-Training CLEAN UP 991 # ---------------------------- 992 log.debug(f"{self.__class__.__name__}: trainer tearing down") File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:1031, in Trainer._run_stage(self) 1029 if self.training: 1030 with isolate_rng(): -> 1031 self._run_sanity_check() 1032 with torch.autograd.set_detect_anomaly(self._detect_anomaly): 1033 self.fit_loop.run() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:1060, in Trainer._run_sanity_check(self) 1057 call._call_callback_hooks(self, "on_sanity_check_start") 1059 # run eval step -> 1060 val_loop.run() 1062 call._call_callback_hooks(self, "on_sanity_check_end") 1064 # reset logger connector File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/utilities.py:182, in _no_grad_context.<locals>._decorator(self, *args, **kwargs) 180 context_manager = torch.no_grad 181 with context_manager(): --> 182 return loop_run(self, *args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/evaluation_loop.py:135, in _EvaluationLoop.run(self) 133 self.batch_progress.is_last_batch = data_fetcher.done 134 # run step hooks --> 135 self._evaluation_step(batch, batch_idx, dataloader_idx, dataloader_iter) 136 except StopIteration: 137 # this needs to wrap the `*_step` call too (not just `next`) for `dataloader_iter` support 138 break File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/evaluation_loop.py:385, in _EvaluationLoop._evaluation_step(self, batch, batch_idx, dataloader_idx, dataloader_iter) 380 trainer._logger_connector.on_batch_start( 381 batch, dataloader_idx if self._is_sequential and self.num_dataloaders > 1 else None 382 ) 384 hook_name = "on_test_batch_start" if trainer.testing else "on_validation_batch_start" --> 385 call._call_callback_hooks(trainer, hook_name, *hook_kwargs.values()) 386 call._call_lightning_module_hook(trainer, hook_name, *hook_kwargs.values()) 388 self.batch_progress.increment_started() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:208, in _call_callback_hooks(trainer, hook_name, monitoring_callbacks, *args, **kwargs) 206 if callable(fn): 207 with trainer.profiler.profile(f"[Callback]{callback.state_key}.{hook_name}"): --> 208 fn(trainer, trainer.lightning_module, *args, **kwargs) 210 if pl_module: 211 # restore current_fx when nested context 212 pl_module._current_fx_name = prev_fx_name File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/ISLP/torch/lightning.py:261, in ErrorTracker.on_validation_batch_start(self, trainer, pl_module, batch, batch_idx, dataloader_idx) 254 def on_validation_batch_start(self, 255 trainer, 256 pl_module, 257 batch, 258 batch_idx, 259 dataloader_idx=0): 260 x, y = batch --> 261 self.val_preds.append(pl_module.forward(x)) 262 self.val_targets.append(y) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/ISLP/torch/lightning.py:151, in SimpleModule.forward(self, x) 150 def forward(self, x): --> 151 return self.model(x) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1532, in Module._wrapped_call_impl(self, *args, **kwargs) 1530 return self._compiled_call_impl(*args, **kwargs) # type: ignore[misc] 1531 else: -> 1532 return self._call_impl(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1541, in Module._call_impl(self, *args, **kwargs) 1536 # If we don't have any hooks, we want to skip the rest of the logic in 1537 # this function, and just call forward. 1538 if not (self._backward_hooks or self._backward_pre_hooks or self._forward_hooks or self._forward_pre_hooks 1539 or _global_backward_pre_hooks or _global_backward_hooks 1540 or _global_forward_hooks or _global_forward_pre_hooks): -> 1541 return forward_call(*args, **kwargs) 1543 try: 1544 result = None Cell In[73], line 17, in IMDBModel.forward(self, x) 11 val = x 12 for _map in [self.dense1, 13 self.activation, 14 self.dense2, 15 self.activation, 16 self.output]: ---> 17 val = _map(val) 18 return torch.flatten(val) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1532, in Module._wrapped_call_impl(self, *args, **kwargs) 1530 return self._compiled_call_impl(*args, **kwargs) # type: ignore[misc] 1531 else: -> 1532 return self._call_impl(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1541, in Module._call_impl(self, *args, **kwargs) 1536 # If we don't have any hooks, we want to skip the rest of the logic in 1537 # this function, and just call forward. 1538 if not (self._backward_hooks or self._backward_pre_hooks or self._forward_hooks or self._forward_pre_hooks 1539 or _global_backward_pre_hooks or _global_backward_hooks 1540 or _global_forward_hooks or _global_forward_pre_hooks): -> 1541 return forward_call(*args, **kwargs) 1543 try: 1544 result = None File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/linear.py:116, in Linear.forward(self, input) 115 def forward(self, input: Tensor) -> Tensor: --> 116 return F.linear(input, self.weight, self.bias) RuntimeError: Deterministic behavior was enabled with either `torch.use_deterministic_algorithms(True)` or `at::Context::setDeterministicAlgorithms(true)`, but this operation is not deterministic because it uses CuBLAS and you have CUDA >= 10.2. To enable deterministic behavior in this case, you must set an environment variable before running your PyTorch application: CUBLAS_WORKSPACE_CONFIG=:4096:8 or CUBLAS_WORKSPACE_CONFIG=:16:8. For more information, go to https://docs.nvidia.com/cuda/cublas/index.html#results-reproducibility
Evaluating the test error yields roughly 86% accuracy.
test_results = imdb_trainer.test(imdb_module, datamodule=imdb_dm)
test_resultsLOCAL_RANK: 0 - CUDA_VISIBLE_DEVICES: [0]--------------------------------------------------------------------------- RuntimeError Traceback (most recent call last) Cell In[77], line 1 ----> 1 test_results = imdb_trainer.test(imdb_module, datamodule=imdb_dm) 2 test_results File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:754, in Trainer.test(self, model, dataloaders, ckpt_path, verbose, datamodule) 752 self.state.status = TrainerStatus.RUNNING 753 self.testing = True --> 754 return call._call_and_handle_interrupt( 755 self, self._test_impl, model, dataloaders, ckpt_path, verbose, datamodule 756 ) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:44, in _call_and_handle_interrupt(trainer, trainer_fn, *args, **kwargs) 42 if trainer.strategy.launcher is not None: 43 return trainer.strategy.launcher.launch(trainer_fn, *args, trainer=trainer, **kwargs) ---> 44 return trainer_fn(*args, **kwargs) 46 except _TunerExitException: 47 _call_teardown_hook(trainer) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:794, in Trainer._test_impl(self, model, dataloaders, ckpt_path, verbose, datamodule) 790 assert self.state.fn is not None 791 ckpt_path = self._checkpoint_connector._select_ckpt_path( 792 self.state.fn, ckpt_path, model_provided=model_provided, model_connected=self.lightning_module is not None 793 ) --> 794 results = self._run(model, ckpt_path=ckpt_path) 795 # remove the tensors from the test results 796 results = convert_tensors_to_scalars(results) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:987, in Trainer._run(self, model, ckpt_path) 982 self._signal_connector.register_signal_handlers() 984 # ---------------------------- 985 # RUN THE TRAINER 986 # ---------------------------- --> 987 results = self._run_stage() 989 # ---------------------------- 990 # POST-Training CLEAN UP 991 # ---------------------------- 992 log.debug(f"{self.__class__.__name__}: trainer tearing down") File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:1026, in Trainer._run_stage(self) 1023 self.lightning_module.zero_grad(**zero_grad_kwargs) 1025 if self.evaluating: -> 1026 return self._evaluation_loop.run() 1027 if self.predicting: 1028 return self.predict_loop.run() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/utilities.py:182, in _no_grad_context.<locals>._decorator(self, *args, **kwargs) 180 context_manager = torch.no_grad 181 with context_manager(): --> 182 return loop_run(self, *args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/evaluation_loop.py:135, in _EvaluationLoop.run(self) 133 self.batch_progress.is_last_batch = data_fetcher.done 134 # run step hooks --> 135 self._evaluation_step(batch, batch_idx, dataloader_idx, dataloader_iter) 136 except StopIteration: 137 # this needs to wrap the `*_step` call too (not just `next`) for `dataloader_iter` support 138 break File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/evaluation_loop.py:385, in _EvaluationLoop._evaluation_step(self, batch, batch_idx, dataloader_idx, dataloader_iter) 380 trainer._logger_connector.on_batch_start( 381 batch, dataloader_idx if self._is_sequential and self.num_dataloaders > 1 else None 382 ) 384 hook_name = "on_test_batch_start" if trainer.testing else "on_validation_batch_start" --> 385 call._call_callback_hooks(trainer, hook_name, *hook_kwargs.values()) 386 call._call_lightning_module_hook(trainer, hook_name, *hook_kwargs.values()) 388 self.batch_progress.increment_started() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:208, in _call_callback_hooks(trainer, hook_name, monitoring_callbacks, *args, **kwargs) 206 if callable(fn): 207 with trainer.profiler.profile(f"[Callback]{callback.state_key}.{hook_name}"): --> 208 fn(trainer, trainer.lightning_module, *args, **kwargs) 210 if pl_module: 211 # restore current_fx when nested context 212 pl_module._current_fx_name = prev_fx_name File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/ISLP/torch/lightning.py:297, in ErrorTracker.on_test_batch_start(self, trainer, pl_module, batch, batch_idx, dataloader_idx) 290 def on_test_batch_start(self, 291 trainer, 292 pl_module, 293 batch, 294 batch_idx, 295 dataloader_idx=0): 296 x, y = batch --> 297 self.test_preds.append(pl_module.forward(x)) 298 self.test_targets.append(y) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/ISLP/torch/lightning.py:151, in SimpleModule.forward(self, x) 150 def forward(self, x): --> 151 return self.model(x) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1532, in Module._wrapped_call_impl(self, *args, **kwargs) 1530 return self._compiled_call_impl(*args, **kwargs) # type: ignore[misc] 1531 else: -> 1532 return self._call_impl(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1541, in Module._call_impl(self, *args, **kwargs) 1536 # If we don't have any hooks, we want to skip the rest of the logic in 1537 # this function, and just call forward. 1538 if not (self._backward_hooks or self._backward_pre_hooks or self._forward_hooks or self._forward_pre_hooks 1539 or _global_backward_pre_hooks or _global_backward_hooks 1540 or _global_forward_hooks or _global_forward_pre_hooks): -> 1541 return forward_call(*args, **kwargs) 1543 try: 1544 result = None Cell In[73], line 17, in IMDBModel.forward(self, x) 11 val = x 12 for _map in [self.dense1, 13 self.activation, 14 self.dense2, 15 self.activation, 16 self.output]: ---> 17 val = _map(val) 18 return torch.flatten(val) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1532, in Module._wrapped_call_impl(self, *args, **kwargs) 1530 return self._compiled_call_impl(*args, **kwargs) # type: ignore[misc] 1531 else: -> 1532 return self._call_impl(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1541, in Module._call_impl(self, *args, **kwargs) 1536 # If we don't have any hooks, we want to skip the rest of the logic in 1537 # this function, and just call forward. 1538 if not (self._backward_hooks or self._backward_pre_hooks or self._forward_hooks or self._forward_pre_hooks 1539 or _global_backward_pre_hooks or _global_backward_hooks 1540 or _global_forward_hooks or _global_forward_pre_hooks): -> 1541 return forward_call(*args, **kwargs) 1543 try: 1544 result = None File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/linear.py:116, in Linear.forward(self, input) 115 def forward(self, input: Tensor) -> Tensor: --> 116 return F.linear(input, self.weight, self.bias) RuntimeError: Deterministic behavior was enabled with either `torch.use_deterministic_algorithms(True)` or `at::Context::setDeterministicAlgorithms(true)`, but this operation is not deterministic because it uses CuBLAS and you have CUDA >= 10.2. To enable deterministic behavior in this case, you must set an environment variable before running your PyTorch application: CUBLAS_WORKSPACE_CONFIG=:4096:8 or CUBLAS_WORKSPACE_CONFIG=:16:8. For more information, go to https://docs.nvidia.com/cuda/cublas/index.html#results-reproducibility
Comparison to Lasso
We now fit a lasso logistic regression model using LogisticRegression() from sklearn. Since sklearn does not recognize the sparse tensors of torch, we use a sparse matrix that is recognized by sklearn.
((X_train, Y_train),
(X_valid, Y_valid),
(X_test, Y_test)) = load_sparse(validation=2000,
random_state=0,
root='data/IMDB')Retrieving "IMDB_X_test.npz" from "http://imdb.jtaylor.su.domains/jtaylor/data/".
Retrieving "IMDB_X_train.npz" from "http://imdb.jtaylor.su.domains/jtaylor/data/".Similar to what we did in Section~, we construct a series of 50 values for the lasso reguralization parameter \lambda.
lam_max = np.abs(X_train.T * (Y_train - Y_train.mean())).max()
lam_val = lam_max * np.exp(np.linspace(np.log(1),
np.log(1e-4), 50))With LogisticRegression() the regularization parameter C is specified as the inverse of \lambda. There are several solvers for logistic regression; here we use liblinear which works well with the sparse input format.
logit = LogisticRegression(penalty='l1',
C=1/lam_max,
solver='liblinear',
warm_start=True,
fit_intercept=True)The path of 50 values takes approximately 40 seconds to run.
coefs = []
intercepts = []
for l in lam_val:
logit.C = 1/l
logit.fit(X_train, Y_train)
coefs.append(logit.coef_.copy())
intercepts.append(logit.intercept_)The coefficient and intercepts have an extraneous dimension which can be removed by the np.squeeze() function.
coefs = np.squeeze(coefs)
intercepts = np.squeeze(intercepts)We’ll now make a plot to compare our neural network results with the lasso.
%%capture
fig, axes = subplots(1, 2, figsize=(16, 8), sharey=True)
for ((X_, Y_),
data_,
color) in zip([(X_train, Y_train),
(X_valid, Y_valid),
(X_test, Y_test)],
['Training', 'Validation', 'Test'],
['black', 'red', 'blue']):
linpred_ = X_ * coefs.T + intercepts[None,:]
label_ = np.array(linpred_ > 0)
accuracy_ = np.array([np.mean(Y_ == l) for l in label_.T])
axes[0].plot(-np.log(lam_val / X_train.shape[0]),
accuracy_,
'.--',
color=color,
markersize=13,
linewidth=2,
label=data_)
axes[0].legend()
axes[0].set_xlabel(r'$-\log(\lambda)$', fontsize=20)
axes[0].set_ylabel('Accuracy', fontsize=20)Notice the use of %%capture, which suppresses the displaying of the partially completed figure. This is useful when making a complex figure, since the steps can be spread across two or more cells. We now add a plot of the lasso accuracy, and display the composed figure by simply entering its name at the end of the cell.
imdb_results = pd.read_csv(imdb_logger.experiment.metrics_file_path)
summary_plot(imdb_results,
axes[1],
col='accuracy',
ylabel='Accuracy')
axes[1].set_xticks(np.linspace(0, 30, 7).astype(int))
axes[1].set_ylabel('Accuracy', fontsize=20)
axes[1].set_xlabel('Epoch', fontsize=20)
axes[1].set_ylim([0.5, 1]);
axes[1].axhline(test_results[0]['test_accuracy'],
color='blue',
linestyle='--',
linewidth=3)
fig--------------------------------------------------------------------------- FileNotFoundError Traceback (most recent call last) Cell In[84], line 1 ----> 1 imdb_results = pd.read_csv(imdb_logger.experiment.metrics_file_path) 2 summary_plot(imdb_results, 3 axes[1], 4 col='accuracy', 5 ylabel='Accuracy') 6 axes[1].set_xticks(np.linspace(0, 30, 7).astype(int)) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/parsers/readers.py:1026, in read_csv(filepath_or_buffer, sep, delimiter, header, names, index_col, usecols, dtype, engine, converters, true_values, false_values, skipinitialspace, skiprows, skipfooter, nrows, na_values, keep_default_na, na_filter, verbose, skip_blank_lines, parse_dates, infer_datetime_format, keep_date_col, date_parser, date_format, dayfirst, cache_dates, iterator, chunksize, compression, thousands, decimal, lineterminator, quotechar, quoting, doublequote, escapechar, comment, encoding, encoding_errors, dialect, on_bad_lines, delim_whitespace, low_memory, memory_map, float_precision, storage_options, dtype_backend) 1013 kwds_defaults = _refine_defaults_read( 1014 dialect, 1015 delimiter, (...) 1022 dtype_backend=dtype_backend, 1023 ) 1024 kwds.update(kwds_defaults) -> 1026 return _read(filepath_or_buffer, kwds) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/parsers/readers.py:620, in _read(filepath_or_buffer, kwds) 617 _validate_names(kwds.get("names", None)) 619 # Create the parser. --> 620 parser = TextFileReader(filepath_or_buffer, **kwds) 622 if chunksize or iterator: 623 return parser File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/parsers/readers.py:1620, in TextFileReader.__init__(self, f, engine, **kwds) 1617 self.options["has_index_names"] = kwds["has_index_names"] 1619 self.handles: IOHandles | None = None -> 1620 self._engine = self._make_engine(f, self.engine) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/parsers/readers.py:1880, in TextFileReader._make_engine(self, f, engine) 1878 if "b" not in mode: 1879 mode += "b" -> 1880 self.handles = get_handle( 1881 f, 1882 mode, 1883 encoding=self.options.get("encoding", None), 1884 compression=self.options.get("compression", None), 1885 memory_map=self.options.get("memory_map", False), 1886 is_text=is_text, 1887 errors=self.options.get("encoding_errors", "strict"), 1888 storage_options=self.options.get("storage_options", None), 1889 ) 1890 assert self.handles is not None 1891 f = self.handles.handle File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/common.py:873, in get_handle(path_or_buf, mode, encoding, compression, memory_map, is_text, errors, storage_options) 868 elif isinstance(handle, str): 869 # Check whether the filename is to be opened in binary mode. 870 # Binary mode does not support 'encoding' and 'newline'. 871 if ioargs.encoding and "b" not in ioargs.mode: 872 # Encoding --> 873 handle = open( 874 handle, 875 ioargs.mode, 876 encoding=ioargs.encoding, 877 errors=errors, 878 newline="", 879 ) 880 else: 881 # Binary mode 882 handle = open(handle, ioargs.mode) FileNotFoundError: [Errno 2] No such file or directory: 'logs/IMDB/version_0/metrics.csv'
From the graphs we see that the accuracy of the lasso logistic regression peaks at about 0.88, as it does for the neural network.
Once again, we end with a cleanup.
del(imdb_model,
imdb_trainer,
imdb_logger,
imdb_dm,
imdb_train,
imdb_test)Recurrent Neural Networks
In this lab we fit the models illustrated in Section~.
Sequential Models for Document Classification
Here we fit a simple LSTM RNN for sentiment prediction to the IMDb movie-review data, as discussed in Section~. For an RNN we use the sequence of words in a document, taking their order into account. We loaded the preprocessed data at the beginning of Section~. A script that details the preprocessing can be found in the ISLP library. Notably, since more than 90% of the documents had fewer than 500 words, we set the document length to 500. For longer documents, we used the last 500 words, and for shorter documents, we padded the front with blanks.
imdb_seq_dm = SimpleDataModule(imdb_seq_train,
imdb_seq_test,
validation=2000,
batch_size=300,
num_workers=min(6, max_num_workers)
)The first layer of the RNN is an embedding layer of size 32, which will be learned during training. This layer one-hot encodes each document as a matrix of dimension 500 \times 10,003, and then maps these 10,003 dimensions down to 32. {The extra 3 dimensions correspond to commonly occurring non-word entries in the reviews.} Since each word is represented by an integer, this is effectively achieved by the creation of an embedding matrix of size 10,003\times 32; each of the 500 integers in the document are then mapped to the appropriate 32 real numbers by indexing the appropriate rows of this matrix.
The second layer is an LSTM with 32 units, and the output layer is a single logit for the binary classification task. In the last line of the forward() method below, we take the last 32-dimensional output of the LSTM and map it to our response.
class LSTMModel(nn.Module):
def __init__(self, input_size):
super(LSTMModel, self).__init__()
self.embedding = nn.Embedding(input_size, 32)
self.lstm = nn.LSTM(input_size=32,
hidden_size=32,
batch_first=True)
self.dense = nn.Linear(32, 1)
def forward(self, x):
val, (h_n, c_n) = self.lstm(self.embedding(x))
return torch.flatten(self.dense(val[:,-1]))We instantiate and take a look at the summary of the model, using the first 10 documents in the corpus.
lstm_model = LSTMModel(X_test.shape[-1])
summary(lstm_model,
input_data=imdb_seq_train.tensors[0][:10],
col_names=['input_size',
'output_size',
'num_params'])===================================================================================================================
Layer (type:depth-idx) Input Shape Output Shape Param #
===================================================================================================================
LSTMModel [10, 500] [10] --
├─Embedding: 1-1 [10, 500] [10, 500, 32] 320,096
├─LSTM: 1-2 [10, 500, 32] [10, 500, 32] 8,448
├─Linear: 1-3 [10, 32] [10, 1] 33
===================================================================================================================
Total params: 328,577
Trainable params: 328,577
Non-trainable params: 0
Total mult-adds (M): 45.44
===================================================================================================================
Input size (MB): 50.00
Forward/backward pass size (MB): 2.56
Params size (MB): 1.31
Estimated Total Size (MB): 53.87
===================================================================================================================The 10,003 is suppressed in the summary, but we see it in the parameter count, since 10,003\times 32=320,096.
lstm_module = SimpleModule.binary_classification(lstm_model)
lstm_logger = CSVLogger('logs', name='IMDB_LSTM')lstm_trainer = Trainer(deterministic=True,
max_epochs=20,
logger=lstm_logger,
enable_progress_bar=False,
callbacks=[ErrorTracker()])
lstm_trainer.fit(lstm_module,
datamodule=imdb_seq_dm)GPU available: True (cuda), used: True
TPU available: False, using: 0 TPU cores
IPU available: False, using: 0 IPUs
HPU available: False, using: 0 HPUs
Missing logger folder: logs/IMDB_LSTM
LOCAL_RANK: 0 - CUDA_VISIBLE_DEVICES: [0]
| Name | Type | Params
--------------------------------------------
0 | model | LSTMModel | 328 K
1 | loss | BCEWithLogitsLoss | 0
--------------------------------------------
328 K Trainable params
0 Non-trainable params
328 K Total params
1.314 Total estimated model params size (MB)--------------------------------------------------------------------------- RuntimeError Traceback (most recent call last) Cell In[90], line 6 1 lstm_trainer = Trainer(deterministic=True, 2 max_epochs=20, 3 logger=lstm_logger, 4 enable_progress_bar=False, 5 callbacks=[ErrorTracker()]) ----> 6 lstm_trainer.fit(lstm_module, 7 datamodule=imdb_seq_dm) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:544, in Trainer.fit(self, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path) 542 self.state.status = TrainerStatus.RUNNING 543 self.training = True --> 544 call._call_and_handle_interrupt( 545 self, self._fit_impl, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path 546 ) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:44, in _call_and_handle_interrupt(trainer, trainer_fn, *args, **kwargs) 42 if trainer.strategy.launcher is not None: 43 return trainer.strategy.launcher.launch(trainer_fn, *args, trainer=trainer, **kwargs) ---> 44 return trainer_fn(*args, **kwargs) 46 except _TunerExitException: 47 _call_teardown_hook(trainer) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:580, in Trainer._fit_impl(self, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path) 573 assert self.state.fn is not None 574 ckpt_path = self._checkpoint_connector._select_ckpt_path( 575 self.state.fn, 576 ckpt_path, 577 model_provided=True, 578 model_connected=self.lightning_module is not None, 579 ) --> 580 self._run(model, ckpt_path=ckpt_path) 582 assert self.state.stopped 583 self.training = False File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:987, in Trainer._run(self, model, ckpt_path) 982 self._signal_connector.register_signal_handlers() 984 # ---------------------------- 985 # RUN THE TRAINER 986 # ---------------------------- --> 987 results = self._run_stage() 989 # ---------------------------- 990 # POST-Training CLEAN UP 991 # ---------------------------- 992 log.debug(f"{self.__class__.__name__}: trainer tearing down") File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:1031, in Trainer._run_stage(self) 1029 if self.training: 1030 with isolate_rng(): -> 1031 self._run_sanity_check() 1032 with torch.autograd.set_detect_anomaly(self._detect_anomaly): 1033 self.fit_loop.run() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:1060, in Trainer._run_sanity_check(self) 1057 call._call_callback_hooks(self, "on_sanity_check_start") 1059 # run eval step -> 1060 val_loop.run() 1062 call._call_callback_hooks(self, "on_sanity_check_end") 1064 # reset logger connector File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/utilities.py:182, in _no_grad_context.<locals>._decorator(self, *args, **kwargs) 180 context_manager = torch.no_grad 181 with context_manager(): --> 182 return loop_run(self, *args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/evaluation_loop.py:135, in _EvaluationLoop.run(self) 133 self.batch_progress.is_last_batch = data_fetcher.done 134 # run step hooks --> 135 self._evaluation_step(batch, batch_idx, dataloader_idx, dataloader_iter) 136 except StopIteration: 137 # this needs to wrap the `*_step` call too (not just `next`) for `dataloader_iter` support 138 break File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/evaluation_loop.py:385, in _EvaluationLoop._evaluation_step(self, batch, batch_idx, dataloader_idx, dataloader_iter) 380 trainer._logger_connector.on_batch_start( 381 batch, dataloader_idx if self._is_sequential and self.num_dataloaders > 1 else None 382 ) 384 hook_name = "on_test_batch_start" if trainer.testing else "on_validation_batch_start" --> 385 call._call_callback_hooks(trainer, hook_name, *hook_kwargs.values()) 386 call._call_lightning_module_hook(trainer, hook_name, *hook_kwargs.values()) 388 self.batch_progress.increment_started() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:208, in _call_callback_hooks(trainer, hook_name, monitoring_callbacks, *args, **kwargs) 206 if callable(fn): 207 with trainer.profiler.profile(f"[Callback]{callback.state_key}.{hook_name}"): --> 208 fn(trainer, trainer.lightning_module, *args, **kwargs) 210 if pl_module: 211 # restore current_fx when nested context 212 pl_module._current_fx_name = prev_fx_name File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/ISLP/torch/lightning.py:261, in ErrorTracker.on_validation_batch_start(self, trainer, pl_module, batch, batch_idx, dataloader_idx) 254 def on_validation_batch_start(self, 255 trainer, 256 pl_module, 257 batch, 258 batch_idx, 259 dataloader_idx=0): 260 x, y = batch --> 261 self.val_preds.append(pl_module.forward(x)) 262 self.val_targets.append(y) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/ISLP/torch/lightning.py:151, in SimpleModule.forward(self, x) 150 def forward(self, x): --> 151 return self.model(x) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1532, in Module._wrapped_call_impl(self, *args, **kwargs) 1530 return self._compiled_call_impl(*args, **kwargs) # type: ignore[misc] 1531 else: -> 1532 return self._call_impl(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1541, in Module._call_impl(self, *args, **kwargs) 1536 # If we don't have any hooks, we want to skip the rest of the logic in 1537 # this function, and just call forward. 1538 if not (self._backward_hooks or self._backward_pre_hooks or self._forward_hooks or self._forward_pre_hooks 1539 or _global_backward_pre_hooks or _global_backward_hooks 1540 or _global_forward_hooks or _global_forward_pre_hooks): -> 1541 return forward_call(*args, **kwargs) 1543 try: 1544 result = None Cell In[87], line 11, in LSTMModel.forward(self, x) 9 def forward(self, x): 10 val, (h_n, c_n) = self.lstm(self.embedding(x)) ---> 11 return torch.flatten(self.dense(val[:,-1])) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1532, in Module._wrapped_call_impl(self, *args, **kwargs) 1530 return self._compiled_call_impl(*args, **kwargs) # type: ignore[misc] 1531 else: -> 1532 return self._call_impl(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1541, in Module._call_impl(self, *args, **kwargs) 1536 # If we don't have any hooks, we want to skip the rest of the logic in 1537 # this function, and just call forward. 1538 if not (self._backward_hooks or self._backward_pre_hooks or self._forward_hooks or self._forward_pre_hooks 1539 or _global_backward_pre_hooks or _global_backward_hooks 1540 or _global_forward_hooks or _global_forward_pre_hooks): -> 1541 return forward_call(*args, **kwargs) 1543 try: 1544 result = None File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/linear.py:116, in Linear.forward(self, input) 115 def forward(self, input: Tensor) -> Tensor: --> 116 return F.linear(input, self.weight, self.bias) RuntimeError: Deterministic behavior was enabled with either `torch.use_deterministic_algorithms(True)` or `at::Context::setDeterministicAlgorithms(true)`, but this operation is not deterministic because it uses CuBLAS and you have CUDA >= 10.2. To enable deterministic behavior in this case, you must set an environment variable before running your PyTorch application: CUBLAS_WORKSPACE_CONFIG=:4096:8 or CUBLAS_WORKSPACE_CONFIG=:16:8. For more information, go to https://docs.nvidia.com/cuda/cublas/index.html#results-reproducibility
The rest is now similar to other networks we have fit. We track the test performance as the network is fit, and see that it attains 85% accuracy.
lstm_trainer.test(lstm_module, datamodule=imdb_seq_dm)LOCAL_RANK: 0 - CUDA_VISIBLE_DEVICES: [0]--------------------------------------------------------------------------- RuntimeError Traceback (most recent call last) Cell In[91], line 1 ----> 1 lstm_trainer.test(lstm_module, datamodule=imdb_seq_dm) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:754, in Trainer.test(self, model, dataloaders, ckpt_path, verbose, datamodule) 752 self.state.status = TrainerStatus.RUNNING 753 self.testing = True --> 754 return call._call_and_handle_interrupt( 755 self, self._test_impl, model, dataloaders, ckpt_path, verbose, datamodule 756 ) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:44, in _call_and_handle_interrupt(trainer, trainer_fn, *args, **kwargs) 42 if trainer.strategy.launcher is not None: 43 return trainer.strategy.launcher.launch(trainer_fn, *args, trainer=trainer, **kwargs) ---> 44 return trainer_fn(*args, **kwargs) 46 except _TunerExitException: 47 _call_teardown_hook(trainer) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:794, in Trainer._test_impl(self, model, dataloaders, ckpt_path, verbose, datamodule) 790 assert self.state.fn is not None 791 ckpt_path = self._checkpoint_connector._select_ckpt_path( 792 self.state.fn, ckpt_path, model_provided=model_provided, model_connected=self.lightning_module is not None 793 ) --> 794 results = self._run(model, ckpt_path=ckpt_path) 795 # remove the tensors from the test results 796 results = convert_tensors_to_scalars(results) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:987, in Trainer._run(self, model, ckpt_path) 982 self._signal_connector.register_signal_handlers() 984 # ---------------------------- 985 # RUN THE TRAINER 986 # ---------------------------- --> 987 results = self._run_stage() 989 # ---------------------------- 990 # POST-Training CLEAN UP 991 # ---------------------------- 992 log.debug(f"{self.__class__.__name__}: trainer tearing down") File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:1026, in Trainer._run_stage(self) 1023 self.lightning_module.zero_grad(**zero_grad_kwargs) 1025 if self.evaluating: -> 1026 return self._evaluation_loop.run() 1027 if self.predicting: 1028 return self.predict_loop.run() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/utilities.py:182, in _no_grad_context.<locals>._decorator(self, *args, **kwargs) 180 context_manager = torch.no_grad 181 with context_manager(): --> 182 return loop_run(self, *args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/evaluation_loop.py:135, in _EvaluationLoop.run(self) 133 self.batch_progress.is_last_batch = data_fetcher.done 134 # run step hooks --> 135 self._evaluation_step(batch, batch_idx, dataloader_idx, dataloader_iter) 136 except StopIteration: 137 # this needs to wrap the `*_step` call too (not just `next`) for `dataloader_iter` support 138 break File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/evaluation_loop.py:385, in _EvaluationLoop._evaluation_step(self, batch, batch_idx, dataloader_idx, dataloader_iter) 380 trainer._logger_connector.on_batch_start( 381 batch, dataloader_idx if self._is_sequential and self.num_dataloaders > 1 else None 382 ) 384 hook_name = "on_test_batch_start" if trainer.testing else "on_validation_batch_start" --> 385 call._call_callback_hooks(trainer, hook_name, *hook_kwargs.values()) 386 call._call_lightning_module_hook(trainer, hook_name, *hook_kwargs.values()) 388 self.batch_progress.increment_started() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:208, in _call_callback_hooks(trainer, hook_name, monitoring_callbacks, *args, **kwargs) 206 if callable(fn): 207 with trainer.profiler.profile(f"[Callback]{callback.state_key}.{hook_name}"): --> 208 fn(trainer, trainer.lightning_module, *args, **kwargs) 210 if pl_module: 211 # restore current_fx when nested context 212 pl_module._current_fx_name = prev_fx_name File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/ISLP/torch/lightning.py:297, in ErrorTracker.on_test_batch_start(self, trainer, pl_module, batch, batch_idx, dataloader_idx) 290 def on_test_batch_start(self, 291 trainer, 292 pl_module, 293 batch, 294 batch_idx, 295 dataloader_idx=0): 296 x, y = batch --> 297 self.test_preds.append(pl_module.forward(x)) 298 self.test_targets.append(y) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/ISLP/torch/lightning.py:151, in SimpleModule.forward(self, x) 150 def forward(self, x): --> 151 return self.model(x) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1532, in Module._wrapped_call_impl(self, *args, **kwargs) 1530 return self._compiled_call_impl(*args, **kwargs) # type: ignore[misc] 1531 else: -> 1532 return self._call_impl(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1541, in Module._call_impl(self, *args, **kwargs) 1536 # If we don't have any hooks, we want to skip the rest of the logic in 1537 # this function, and just call forward. 1538 if not (self._backward_hooks or self._backward_pre_hooks or self._forward_hooks or self._forward_pre_hooks 1539 or _global_backward_pre_hooks or _global_backward_hooks 1540 or _global_forward_hooks or _global_forward_pre_hooks): -> 1541 return forward_call(*args, **kwargs) 1543 try: 1544 result = None Cell In[87], line 11, in LSTMModel.forward(self, x) 9 def forward(self, x): 10 val, (h_n, c_n) = self.lstm(self.embedding(x)) ---> 11 return torch.flatten(self.dense(val[:,-1])) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1532, in Module._wrapped_call_impl(self, *args, **kwargs) 1530 return self._compiled_call_impl(*args, **kwargs) # type: ignore[misc] 1531 else: -> 1532 return self._call_impl(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1541, in Module._call_impl(self, *args, **kwargs) 1536 # If we don't have any hooks, we want to skip the rest of the logic in 1537 # this function, and just call forward. 1538 if not (self._backward_hooks or self._backward_pre_hooks or self._forward_hooks or self._forward_pre_hooks 1539 or _global_backward_pre_hooks or _global_backward_hooks 1540 or _global_forward_hooks or _global_forward_pre_hooks): -> 1541 return forward_call(*args, **kwargs) 1543 try: 1544 result = None File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/linear.py:116, in Linear.forward(self, input) 115 def forward(self, input: Tensor) -> Tensor: --> 116 return F.linear(input, self.weight, self.bias) RuntimeError: Deterministic behavior was enabled with either `torch.use_deterministic_algorithms(True)` or `at::Context::setDeterministicAlgorithms(true)`, but this operation is not deterministic because it uses CuBLAS and you have CUDA >= 10.2. To enable deterministic behavior in this case, you must set an environment variable before running your PyTorch application: CUBLAS_WORKSPACE_CONFIG=:4096:8 or CUBLAS_WORKSPACE_CONFIG=:16:8. For more information, go to https://docs.nvidia.com/cuda/cublas/index.html#results-reproducibility
We once again show the learning progress, followed by cleanup.
lstm_results = pd.read_csv(lstm_logger.experiment.metrics_file_path)
fig, ax = subplots(1, 1, figsize=(6, 6))
summary_plot(lstm_results,
ax,
col='accuracy',
ylabel='Accuracy')
ax.set_xticks(np.linspace(0, 20, 5).astype(int))
ax.set_ylabel('Accuracy')
ax.set_ylim([0.5, 1])--------------------------------------------------------------------------- FileNotFoundError Traceback (most recent call last) Cell In[92], line 1 ----> 1 lstm_results = pd.read_csv(lstm_logger.experiment.metrics_file_path) 2 fig, ax = subplots(1, 1, figsize=(6, 6)) 3 summary_plot(lstm_results, 4 ax, 5 col='accuracy', 6 ylabel='Accuracy') File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/parsers/readers.py:1026, in read_csv(filepath_or_buffer, sep, delimiter, header, names, index_col, usecols, dtype, engine, converters, true_values, false_values, skipinitialspace, skiprows, skipfooter, nrows, na_values, keep_default_na, na_filter, verbose, skip_blank_lines, parse_dates, infer_datetime_format, keep_date_col, date_parser, date_format, dayfirst, cache_dates, iterator, chunksize, compression, thousands, decimal, lineterminator, quotechar, quoting, doublequote, escapechar, comment, encoding, encoding_errors, dialect, on_bad_lines, delim_whitespace, low_memory, memory_map, float_precision, storage_options, dtype_backend) 1013 kwds_defaults = _refine_defaults_read( 1014 dialect, 1015 delimiter, (...) 1022 dtype_backend=dtype_backend, 1023 ) 1024 kwds.update(kwds_defaults) -> 1026 return _read(filepath_or_buffer, kwds) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/parsers/readers.py:620, in _read(filepath_or_buffer, kwds) 617 _validate_names(kwds.get("names", None)) 619 # Create the parser. --> 620 parser = TextFileReader(filepath_or_buffer, **kwds) 622 if chunksize or iterator: 623 return parser File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/parsers/readers.py:1620, in TextFileReader.__init__(self, f, engine, **kwds) 1617 self.options["has_index_names"] = kwds["has_index_names"] 1619 self.handles: IOHandles | None = None -> 1620 self._engine = self._make_engine(f, self.engine) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/parsers/readers.py:1880, in TextFileReader._make_engine(self, f, engine) 1878 if "b" not in mode: 1879 mode += "b" -> 1880 self.handles = get_handle( 1881 f, 1882 mode, 1883 encoding=self.options.get("encoding", None), 1884 compression=self.options.get("compression", None), 1885 memory_map=self.options.get("memory_map", False), 1886 is_text=is_text, 1887 errors=self.options.get("encoding_errors", "strict"), 1888 storage_options=self.options.get("storage_options", None), 1889 ) 1890 assert self.handles is not None 1891 f = self.handles.handle File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pandas/io/common.py:873, in get_handle(path_or_buf, mode, encoding, compression, memory_map, is_text, errors, storage_options) 868 elif isinstance(handle, str): 869 # Check whether the filename is to be opened in binary mode. 870 # Binary mode does not support 'encoding' and 'newline'. 871 if ioargs.encoding and "b" not in ioargs.mode: 872 # Encoding --> 873 handle = open( 874 handle, 875 ioargs.mode, 876 encoding=ioargs.encoding, 877 errors=errors, 878 newline="", 879 ) 880 else: 881 # Binary mode 882 handle = open(handle, ioargs.mode) FileNotFoundError: [Errno 2] No such file or directory: 'logs/IMDB_LSTM/version_0/metrics.csv'
del(lstm_model,
lstm_trainer,
lstm_logger,
imdb_seq_dm,
imdb_seq_train,
imdb_seq_test)Time Series Prediction
We now show how to fit the models in Section~ for time series prediction. We first load and standardize the data.
NYSE = load_data('NYSE')
cols = ['DJ_return', 'log_volume', 'log_volatility']
X = pd.DataFrame(StandardScaler(
with_mean=True,
with_std=True).fit_transform(NYSE[cols]),
columns=NYSE[cols].columns,
index=NYSE.index)Next we set up the lagged versions of the data, dropping any rows with missing values using the dropna() method.
for lag in range(1, 6):
for col in cols:
newcol = np.zeros(X.shape[0]) * np.nan
newcol[lag:] = X[col].values[:-lag]
X.insert(len(X.columns), "{0}_{1}".format(col, lag), newcol)
X.insert(len(X.columns), 'train', NYSE['train'])
X = X.dropna()Finally, we extract the response, training indicator, and drop the current day’s DJ_return and log_volatility to predict only from previous day’s data.
Y, train = X['log_volume'], X['train']
X = X.drop(columns=['train'] + cols)
X.columnsIndex(['DJ_return_1', 'log_volume_1', 'log_volatility_1', 'DJ_return_2',
'log_volume_2', 'log_volatility_2', 'DJ_return_3', 'log_volume_3',
'log_volatility_3', 'DJ_return_4', 'log_volume_4', 'log_volatility_4',
'DJ_return_5', 'log_volume_5', 'log_volatility_5'],
dtype='object')We first fit a simple linear model and compute the R^2 on the test data using the score() method.
M = LinearRegression()
M.fit(X[train], Y[train])
M.score(X[~train], Y[~train])0.4128912938562521We refit this model, including the factor variable day_of_week. For a categorical series in pandas, we can form the indicators using the get_dummies() method.
X_day = pd.concat([X,
pd.get_dummies(NYSE['day_of_week'])],
axis=1).dropna()Note that we do not have to reinstantiate the linear regression model as its fit() method accepts a design matrix and a response directly.
M.fit(X_day[train], Y[train])
M.score(X_day[~train], Y[~train])0.4595563133053274This model achieves an R^2 of about 46%.
To fit the RNN, we must reshape the data, as it will expect 5 lagged versions of each feature as indicated by the input_shape argument to the layer nn.RNN() below. We first ensure the columns of our data frame are such that a reshaped matrix will have the variables correctly lagged. We use the reindex() method to do this.
For an input shape (5,3), each row represents a lagged version of the three variables. The nn.RNN() layer also expects the first row of each observation to be earliest in time, so we must reverse the current order. Hence we loop over range(5,0,-1) below, which is an example of using a slice() to index iterable objects. The general notation is start:end:step.
ordered_cols = []
for lag in range(5,0,-1):
for col in cols:
ordered_cols.append('{0}_{1}'.format(col, lag))
X = X.reindex(columns=ordered_cols)
X.columnsIndex(['DJ_return_5', 'log_volume_5', 'log_volatility_5', 'DJ_return_4',
'log_volume_4', 'log_volatility_4', 'DJ_return_3', 'log_volume_3',
'log_volatility_3', 'DJ_return_2', 'log_volume_2', 'log_volatility_2',
'DJ_return_1', 'log_volume_1', 'log_volatility_1'],
dtype='object')We now reshape the data.
X_rnn = X.to_numpy().reshape((-1,5,3))
X_rnn.shape(6046, 5, 3)By specifying the first size as -1, numpy.reshape() deduces its size based on the remaining arguments.
Now we are ready to proceed with the RNN, which uses 12 hidden units, and 10% dropout. After passing through the RNN, we extract the final time point as val[:,-1] in forward() below. This gets passed through a 10% dropout and then flattened through a linear layer.
class NYSEModel(nn.Module):
def __init__(self):
super(NYSEModel, self).__init__()
self.rnn = nn.RNN(3,
12,
batch_first=True)
self.dense = nn.Linear(12, 1)
self.dropout = nn.Dropout(0.1)
def forward(self, x):
val, h_n = self.rnn(x)
val = self.dense(self.dropout(val[:,-1]))
return torch.flatten(val)
nyse_model = NYSEModel()We fit the model in a similar fashion to previous networks. We supply the fit function with test data as validation data, so that when we monitor its progress and plot the history function we can see the progress on the test data. Of course we should not use this as a basis for early stopping, since then the test performance would be biased.
We form the training dataset similar to our Hitters example.
datasets = []
for mask in [train, ~train]:
X_rnn_t = torch.tensor(X_rnn[mask].astype(np.float32))
Y_t = torch.tensor(Y[mask].astype(np.float32))
datasets.append(TensorDataset(X_rnn_t, Y_t))
nyse_train, nyse_test = datasets/tmp/ipykernel_126815/2100042546.py:4: FutureWarning: Series.__getitem__ treating keys as positions is deprecated. In a future version, integer keys will always be treated as labels (consistent with DataFrame behavior). To access a value by position, use `ser.iloc[pos]`
Y_t = torch.tensor(Y[mask].astype(np.float32))
/tmp/ipykernel_126815/2100042546.py:4: FutureWarning: Series.__getitem__ treating keys as positions is deprecated. In a future version, integer keys will always be treated as labels (consistent with DataFrame behavior). To access a value by position, use `ser.iloc[pos]`
Y_t = torch.tensor(Y[mask].astype(np.float32))Following our usual pattern, we inspect the summary.
summary(nyse_model,
input_data=X_rnn_t,
col_names=['input_size',
'output_size',
'num_params'])===================================================================================================================
Layer (type:depth-idx) Input Shape Output Shape Param #
===================================================================================================================
NYSEModel [1770, 5, 3] [1770] --
├─RNN: 1-1 [1770, 5, 3] [1770, 5, 12] 204
├─Dropout: 1-2 [1770, 12] [1770, 12] --
├─Linear: 1-3 [1770, 12] [1770, 1] 13
===================================================================================================================
Total params: 217
Trainable params: 217
Non-trainable params: 0
Total mult-adds (M): 1.83
===================================================================================================================
Input size (MB): 0.11
Forward/backward pass size (MB): 0.86
Params size (MB): 0.00
Estimated Total Size (MB): 0.97
===================================================================================================================We again put the two datasets into a data module, with a batch size of 64.
nyse_dm = SimpleDataModule(nyse_train,
nyse_test,
num_workers=min(4, max_num_workers),
validation=nyse_test,
batch_size=64)We run some data through our model to be sure the sizes match up correctly.
for idx, (x, y) in enumerate(nyse_dm.train_dataloader()):
out = nyse_model(x)
print(y.size(), out.size())
if idx >= 2:
breaktorch.Size([64]) torch.Size([64])
torch.Size([64]) torch.Size([64])
torch.Size([64]) torch.Size([64])We follow our previous example for setting up a trainer for a regression problem, requesting the R^2 metric to be be computed at each epoch.
nyse_optimizer = RMSprop(nyse_model.parameters(),
lr=0.001)
nyse_module = SimpleModule.regression(nyse_model,
optimizer=nyse_optimizer,
metrics={'r2':R2Score()})Fitting the model should by now be familiar. The results on the test data are very similar to the linear AR model.
nyse_trainer = Trainer(deterministic=True,
max_epochs=200,
enable_progress_bar=False,
callbacks=[ErrorTracker()])
nyse_trainer.fit(nyse_module,
datamodule=nyse_dm)
nyse_trainer.test(nyse_module,
datamodule=nyse_dm)GPU available: True (cuda), used: True
TPU available: False, using: 0 TPU cores
IPU available: False, using: 0 IPUs
HPU available: False, using: 0 HPUs
LOCAL_RANK: 0 - CUDA_VISIBLE_DEVICES: [0]
| Name | Type | Params
------------------------------------
0 | model | NYSEModel | 217
1 | loss | MSELoss | 0
------------------------------------
217 Trainable params
0 Non-trainable params
217 Total params
0.001 Total estimated model params size (MB)--------------------------------------------------------------------------- RuntimeError Traceback (most recent call last) Cell In[108], line 5 1 nyse_trainer = Trainer(deterministic=True, 2 max_epochs=200, 3 enable_progress_bar=False, 4 callbacks=[ErrorTracker()]) ----> 5 nyse_trainer.fit(nyse_module, 6 datamodule=nyse_dm) 7 nyse_trainer.test(nyse_module, 8 datamodule=nyse_dm) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:544, in Trainer.fit(self, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path) 542 self.state.status = TrainerStatus.RUNNING 543 self.training = True --> 544 call._call_and_handle_interrupt( 545 self, self._fit_impl, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path 546 ) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:44, in _call_and_handle_interrupt(trainer, trainer_fn, *args, **kwargs) 42 if trainer.strategy.launcher is not None: 43 return trainer.strategy.launcher.launch(trainer_fn, *args, trainer=trainer, **kwargs) ---> 44 return trainer_fn(*args, **kwargs) 46 except _TunerExitException: 47 _call_teardown_hook(trainer) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:580, in Trainer._fit_impl(self, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path) 573 assert self.state.fn is not None 574 ckpt_path = self._checkpoint_connector._select_ckpt_path( 575 self.state.fn, 576 ckpt_path, 577 model_provided=True, 578 model_connected=self.lightning_module is not None, 579 ) --> 580 self._run(model, ckpt_path=ckpt_path) 582 assert self.state.stopped 583 self.training = False File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:987, in Trainer._run(self, model, ckpt_path) 982 self._signal_connector.register_signal_handlers() 984 # ---------------------------- 985 # RUN THE TRAINER 986 # ---------------------------- --> 987 results = self._run_stage() 989 # ---------------------------- 990 # POST-Training CLEAN UP 991 # ---------------------------- 992 log.debug(f"{self.__class__.__name__}: trainer tearing down") File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:1031, in Trainer._run_stage(self) 1029 if self.training: 1030 with isolate_rng(): -> 1031 self._run_sanity_check() 1032 with torch.autograd.set_detect_anomaly(self._detect_anomaly): 1033 self.fit_loop.run() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:1060, in Trainer._run_sanity_check(self) 1057 call._call_callback_hooks(self, "on_sanity_check_start") 1059 # run eval step -> 1060 val_loop.run() 1062 call._call_callback_hooks(self, "on_sanity_check_end") 1064 # reset logger connector File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/utilities.py:182, in _no_grad_context.<locals>._decorator(self, *args, **kwargs) 180 context_manager = torch.no_grad 181 with context_manager(): --> 182 return loop_run(self, *args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/evaluation_loop.py:135, in _EvaluationLoop.run(self) 133 self.batch_progress.is_last_batch = data_fetcher.done 134 # run step hooks --> 135 self._evaluation_step(batch, batch_idx, dataloader_idx, dataloader_iter) 136 except StopIteration: 137 # this needs to wrap the `*_step` call too (not just `next`) for `dataloader_iter` support 138 break File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/evaluation_loop.py:385, in _EvaluationLoop._evaluation_step(self, batch, batch_idx, dataloader_idx, dataloader_iter) 380 trainer._logger_connector.on_batch_start( 381 batch, dataloader_idx if self._is_sequential and self.num_dataloaders > 1 else None 382 ) 384 hook_name = "on_test_batch_start" if trainer.testing else "on_validation_batch_start" --> 385 call._call_callback_hooks(trainer, hook_name, *hook_kwargs.values()) 386 call._call_lightning_module_hook(trainer, hook_name, *hook_kwargs.values()) 388 self.batch_progress.increment_started() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:208, in _call_callback_hooks(trainer, hook_name, monitoring_callbacks, *args, **kwargs) 206 if callable(fn): 207 with trainer.profiler.profile(f"[Callback]{callback.state_key}.{hook_name}"): --> 208 fn(trainer, trainer.lightning_module, *args, **kwargs) 210 if pl_module: 211 # restore current_fx when nested context 212 pl_module._current_fx_name = prev_fx_name File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/ISLP/torch/lightning.py:261, in ErrorTracker.on_validation_batch_start(self, trainer, pl_module, batch, batch_idx, dataloader_idx) 254 def on_validation_batch_start(self, 255 trainer, 256 pl_module, 257 batch, 258 batch_idx, 259 dataloader_idx=0): 260 x, y = batch --> 261 self.val_preds.append(pl_module.forward(x)) 262 self.val_targets.append(y) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/ISLP/torch/lightning.py:151, in SimpleModule.forward(self, x) 150 def forward(self, x): --> 151 return self.model(x) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1532, in Module._wrapped_call_impl(self, *args, **kwargs) 1530 return self._compiled_call_impl(*args, **kwargs) # type: ignore[misc] 1531 else: -> 1532 return self._call_impl(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1541, in Module._call_impl(self, *args, **kwargs) 1536 # If we don't have any hooks, we want to skip the rest of the logic in 1537 # this function, and just call forward. 1538 if not (self._backward_hooks or self._backward_pre_hooks or self._forward_hooks or self._forward_pre_hooks 1539 or _global_backward_pre_hooks or _global_backward_hooks 1540 or _global_forward_hooks or _global_forward_pre_hooks): -> 1541 return forward_call(*args, **kwargs) 1543 try: 1544 result = None Cell In[102], line 11, in NYSEModel.forward(self, x) 9 def forward(self, x): 10 val, h_n = self.rnn(x) ---> 11 val = self.dense(self.dropout(val[:,-1])) 12 return torch.flatten(val) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1532, in Module._wrapped_call_impl(self, *args, **kwargs) 1530 return self._compiled_call_impl(*args, **kwargs) # type: ignore[misc] 1531 else: -> 1532 return self._call_impl(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1541, in Module._call_impl(self, *args, **kwargs) 1536 # If we don't have any hooks, we want to skip the rest of the logic in 1537 # this function, and just call forward. 1538 if not (self._backward_hooks or self._backward_pre_hooks or self._forward_hooks or self._forward_pre_hooks 1539 or _global_backward_pre_hooks or _global_backward_hooks 1540 or _global_forward_hooks or _global_forward_pre_hooks): -> 1541 return forward_call(*args, **kwargs) 1543 try: 1544 result = None File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/linear.py:116, in Linear.forward(self, input) 115 def forward(self, input: Tensor) -> Tensor: --> 116 return F.linear(input, self.weight, self.bias) RuntimeError: Deterministic behavior was enabled with either `torch.use_deterministic_algorithms(True)` or `at::Context::setDeterministicAlgorithms(true)`, but this operation is not deterministic because it uses CuBLAS and you have CUDA >= 10.2. To enable deterministic behavior in this case, you must set an environment variable before running your PyTorch application: CUBLAS_WORKSPACE_CONFIG=:4096:8 or CUBLAS_WORKSPACE_CONFIG=:16:8. For more information, go to https://docs.nvidia.com/cuda/cublas/index.html#results-reproducibility
We could also fit a model without the nn.RNN() layer by just using a nn.Flatten() layer instead. This would be a nonlinear AR model. If in addition we excluded the hidden layer, this would be equivalent to our earlier linear AR model.
Instead we will fit a nonlinear AR model using the feature set X_day that includes the day_of_week indicators. To do so, we must first create our test and training datasets and a corresponding data module. This may seem a little burdensome, but is part of the general pipeline for torch.
datasets = []
for mask in [train, ~train]:
X_day_t = torch.tensor(
np.asarray(X_day[mask]).astype(np.float32))
Y_t = torch.tensor(np.asarray(Y[mask]).astype(np.float32))
datasets.append(TensorDataset(X_day_t, Y_t))
day_train, day_test = datasetsCreating a data module follows a familiar pattern.
day_dm = SimpleDataModule(day_train,
day_test,
num_workers=min(4, max_num_workers),
validation=day_test,
batch_size=64)We build a NonLinearARModel() that takes as input the 20 features and a hidden layer with 32 units. The remaining steps are familiar.
class NonLinearARModel(nn.Module):
def __init__(self):
super(NonLinearARModel, self).__init__()
self._forward = nn.Sequential(nn.Flatten(),
nn.Linear(20, 32),
nn.ReLU(),
nn.Dropout(0.5),
nn.Linear(32, 1))
def forward(self, x):
return torch.flatten(self._forward(x))nl_model = NonLinearARModel()
nl_optimizer = RMSprop(nl_model.parameters(),
lr=0.001)
nl_module = SimpleModule.regression(nl_model,
optimizer=nl_optimizer,
metrics={'r2':R2Score()})We continue with the usual training steps, fit the model, and evaluate the test error. We see the test R^2 is a slight improvement over the linear AR model that also includes day_of_week.
nl_trainer = Trainer(deterministic=True,
max_epochs=20,
enable_progress_bar=False,
callbacks=[ErrorTracker()])
nl_trainer.fit(nl_module, datamodule=day_dm)
nl_trainer.test(nl_module, datamodule=day_dm) GPU available: True (cuda), used: True
TPU available: False, using: 0 TPU cores
IPU available: False, using: 0 IPUs
HPU available: False, using: 0 HPUs
LOCAL_RANK: 0 - CUDA_VISIBLE_DEVICES: [0]
| Name | Type | Params
-------------------------------------------
0 | model | NonLinearARModel | 705
1 | loss | MSELoss | 0
-------------------------------------------
705 Trainable params
0 Non-trainable params
705 Total params
0.003 Total estimated model params size (MB)--------------------------------------------------------------------------- RuntimeError Traceback (most recent call last) Cell In[113], line 5 1 nl_trainer = Trainer(deterministic=True, 2 max_epochs=20, 3 enable_progress_bar=False, 4 callbacks=[ErrorTracker()]) ----> 5 nl_trainer.fit(nl_module, datamodule=day_dm) 6 nl_trainer.test(nl_module, datamodule=day_dm) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:544, in Trainer.fit(self, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path) 542 self.state.status = TrainerStatus.RUNNING 543 self.training = True --> 544 call._call_and_handle_interrupt( 545 self, self._fit_impl, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path 546 ) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:44, in _call_and_handle_interrupt(trainer, trainer_fn, *args, **kwargs) 42 if trainer.strategy.launcher is not None: 43 return trainer.strategy.launcher.launch(trainer_fn, *args, trainer=trainer, **kwargs) ---> 44 return trainer_fn(*args, **kwargs) 46 except _TunerExitException: 47 _call_teardown_hook(trainer) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:580, in Trainer._fit_impl(self, model, train_dataloaders, val_dataloaders, datamodule, ckpt_path) 573 assert self.state.fn is not None 574 ckpt_path = self._checkpoint_connector._select_ckpt_path( 575 self.state.fn, 576 ckpt_path, 577 model_provided=True, 578 model_connected=self.lightning_module is not None, 579 ) --> 580 self._run(model, ckpt_path=ckpt_path) 582 assert self.state.stopped 583 self.training = False File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:987, in Trainer._run(self, model, ckpt_path) 982 self._signal_connector.register_signal_handlers() 984 # ---------------------------- 985 # RUN THE TRAINER 986 # ---------------------------- --> 987 results = self._run_stage() 989 # ---------------------------- 990 # POST-Training CLEAN UP 991 # ---------------------------- 992 log.debug(f"{self.__class__.__name__}: trainer tearing down") File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:1031, in Trainer._run_stage(self) 1029 if self.training: 1030 with isolate_rng(): -> 1031 self._run_sanity_check() 1032 with torch.autograd.set_detect_anomaly(self._detect_anomaly): 1033 self.fit_loop.run() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/trainer.py:1060, in Trainer._run_sanity_check(self) 1057 call._call_callback_hooks(self, "on_sanity_check_start") 1059 # run eval step -> 1060 val_loop.run() 1062 call._call_callback_hooks(self, "on_sanity_check_end") 1064 # reset logger connector File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/utilities.py:182, in _no_grad_context.<locals>._decorator(self, *args, **kwargs) 180 context_manager = torch.no_grad 181 with context_manager(): --> 182 return loop_run(self, *args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/evaluation_loop.py:135, in _EvaluationLoop.run(self) 133 self.batch_progress.is_last_batch = data_fetcher.done 134 # run step hooks --> 135 self._evaluation_step(batch, batch_idx, dataloader_idx, dataloader_iter) 136 except StopIteration: 137 # this needs to wrap the `*_step` call too (not just `next`) for `dataloader_iter` support 138 break File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/loops/evaluation_loop.py:385, in _EvaluationLoop._evaluation_step(self, batch, batch_idx, dataloader_idx, dataloader_iter) 380 trainer._logger_connector.on_batch_start( 381 batch, dataloader_idx if self._is_sequential and self.num_dataloaders > 1 else None 382 ) 384 hook_name = "on_test_batch_start" if trainer.testing else "on_validation_batch_start" --> 385 call._call_callback_hooks(trainer, hook_name, *hook_kwargs.values()) 386 call._call_lightning_module_hook(trainer, hook_name, *hook_kwargs.values()) 388 self.batch_progress.increment_started() File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/pytorch_lightning/trainer/call.py:208, in _call_callback_hooks(trainer, hook_name, monitoring_callbacks, *args, **kwargs) 206 if callable(fn): 207 with trainer.profiler.profile(f"[Callback]{callback.state_key}.{hook_name}"): --> 208 fn(trainer, trainer.lightning_module, *args, **kwargs) 210 if pl_module: 211 # restore current_fx when nested context 212 pl_module._current_fx_name = prev_fx_name File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/ISLP/torch/lightning.py:261, in ErrorTracker.on_validation_batch_start(self, trainer, pl_module, batch, batch_idx, dataloader_idx) 254 def on_validation_batch_start(self, 255 trainer, 256 pl_module, 257 batch, 258 batch_idx, 259 dataloader_idx=0): 260 x, y = batch --> 261 self.val_preds.append(pl_module.forward(x)) 262 self.val_targets.append(y) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/ISLP/torch/lightning.py:151, in SimpleModule.forward(self, x) 150 def forward(self, x): --> 151 return self.model(x) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1532, in Module._wrapped_call_impl(self, *args, **kwargs) 1530 return self._compiled_call_impl(*args, **kwargs) # type: ignore[misc] 1531 else: -> 1532 return self._call_impl(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1541, in Module._call_impl(self, *args, **kwargs) 1536 # If we don't have any hooks, we want to skip the rest of the logic in 1537 # this function, and just call forward. 1538 if not (self._backward_hooks or self._backward_pre_hooks or self._forward_hooks or self._forward_pre_hooks 1539 or _global_backward_pre_hooks or _global_backward_hooks 1540 or _global_forward_hooks or _global_forward_pre_hooks): -> 1541 return forward_call(*args, **kwargs) 1543 try: 1544 result = None Cell In[111], line 10, in NonLinearARModel.forward(self, x) 9 def forward(self, x): ---> 10 return torch.flatten(self._forward(x)) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1532, in Module._wrapped_call_impl(self, *args, **kwargs) 1530 return self._compiled_call_impl(*args, **kwargs) # type: ignore[misc] 1531 else: -> 1532 return self._call_impl(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1541, in Module._call_impl(self, *args, **kwargs) 1536 # If we don't have any hooks, we want to skip the rest of the logic in 1537 # this function, and just call forward. 1538 if not (self._backward_hooks or self._backward_pre_hooks or self._forward_hooks or self._forward_pre_hooks 1539 or _global_backward_pre_hooks or _global_backward_hooks 1540 or _global_forward_hooks or _global_forward_pre_hooks): -> 1541 return forward_call(*args, **kwargs) 1543 try: 1544 result = None File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/container.py:217, in Sequential.forward(self, input) 215 def forward(self, input): 216 for module in self: --> 217 input = module(input) 218 return input File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1532, in Module._wrapped_call_impl(self, *args, **kwargs) 1530 return self._compiled_call_impl(*args, **kwargs) # type: ignore[misc] 1531 else: -> 1532 return self._call_impl(*args, **kwargs) File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/module.py:1541, in Module._call_impl(self, *args, **kwargs) 1536 # If we don't have any hooks, we want to skip the rest of the logic in 1537 # this function, and just call forward. 1538 if not (self._backward_hooks or self._backward_pre_hooks or self._forward_hooks or self._forward_pre_hooks 1539 or _global_backward_pre_hooks or _global_backward_hooks 1540 or _global_forward_hooks or _global_forward_pre_hooks): -> 1541 return forward_call(*args, **kwargs) 1543 try: 1544 result = None File ~/work/notes/notes-islr-py/.venv/lib/python3.10/site-packages/torch/nn/modules/linear.py:116, in Linear.forward(self, input) 115 def forward(self, input: Tensor) -> Tensor: --> 116 return F.linear(input, self.weight, self.bias) RuntimeError: Deterministic behavior was enabled with either `torch.use_deterministic_algorithms(True)` or `at::Context::setDeterministicAlgorithms(true)`, but this operation is not deterministic because it uses CuBLAS and you have CUDA >= 10.2. To enable deterministic behavior in this case, you must set an environment variable before running your PyTorch application: CUBLAS_WORKSPACE_CONFIG=:4096:8 or CUBLAS_WORKSPACE_CONFIG=:16:8. For more information, go to https://docs.nvidia.com/cuda/cublas/index.html#results-reproducibility
Reuse
CC SA BY-NC-ND
Citation
BibTeX citation:
@online{bochman2024,
author = {Bochman, Oren},
title = {Chapter 10: {Deep} {Learning}},
date = {2024-08-21},
url = {https://orenbochman.github.io/notes-islr/posts/ch10/Ch10-deeplearning-lab.html},
langid = {en}
}
For attribution, please cite this work as:
Bochman, Oren. 2024. “Chapter 10: Deep Learning.” August
21, 2024. https://orenbochman.github.io/notes-islr/posts/ch10/Ch10-deeplearning-lab.html.
